Cisco Catalyst 6500 Series DFC 3a for 6500 FE Modules & 6816 Line Card

Catalyst 6500 Distributed Forwarding Card-3 Video Data Sheet

Video Data Sheet

The Distributed Forwarding Card 3C enables distributed forwarding on the Catalyst 6500 and is compatible with the Virtual Switching System 1440. (22:18 min)

Viewing this embedded video requires the latest version of Adobe Flash Player with JavaScript enabled.
Get the Flash Player

WS-F6K-DFC3

The Catalyst 6500 Distributed Forwarding Card-3 is installed in DFC-enabled line-card modules that perform distributed forwarding supported by the Catalyst 6500 Supervisor Engine 720 as a field upgrade. These line cards include the WS-X6516-GBIC and the WS-X6816-GBIC.

Key Features:

When the Distributed Forwarding Card-3 is installed, modules that are DFC-enabled make forwarding decisions locally, leaving the supervisor engine free to perform routing and management functions.

The Distributed Forwarding Card-3 replicates Layer 2 and 3 forwarding logic of the Supervisor 720's PFC-3 on each DFC-3 equipped linecard. This enables hardware acceleration of IPv6, MPLS, GRE, QoS, ACL policy enforcement and more. The DFC-3 equipped interface modules are backward compatible with all other Catalyst 6500 interface modules. However, they must be used with a Supervisor 720 and any other modules that will use distributed forwarding must also be DFC-3 equipped.
