The Cisco MDS 9513 Multilayer Director is a high-performance, protocol-independent, director-class SAN switch that meets stringent enterprise data center storage requirements. Compatible with all generations of Cisco MDS 9000 switching modules, it provides high availability, scalability, security, and transparent integration of intelligent features.

Feature and Capabilities

  • Scalable expansion with outstanding investment protection
  • Multiprotocol architecture and convergence with multihop FCoE
  • Business transformation with enterprise cloud deployments
  • Platform for intelligent storage applications

Enterprise-Class Availability

The Cisco MDS 9513 Multilayer Director helps you meet server virtualization challenges such as:

  • Increased need for servers to access data on the network
  • Higher bandwidth density per server
  • Different security profiles for multitenancy, cloud computing, and heterogeneous environments
  • Loss of insight into individual applications for the SAN administration team

Converge Networks for Easy Storage Connectivity

You can easily connect a Cisco MDS-based SAN infrastructure to large converged networks with multihop Fibre Channel over Ethernet (FCoE). In addition, the operating system and management interface are the same as for all other Cisco data center switches.

Scale Your SAN for High Performance

With the Cisco MDS 9513 Multilayer Director, you can consolidate highly virtualized servers and high-end storage in a SAN. The Cisco MDS 9513 supports up to 528 high-performance 1, 2, 4, and 8 Gbps Fibre Channel ports in one chassis.

Use Intelligent Storage for Mixed Environments

This SAN switch offers intelligence for heterogeneous environments with:

Cisco Data Center Network Manager offers end-to-end, virtual-machine-aware path analytics and trending, to help you simplify management of your data center virtual infrastructure.

Related Links

Services

Solutions

Specifications at a Glance

Software compatibility Cisco MDS SAN-OS Software Release 3.0(1) or later
Note: MDS 9513 Crossbar Switching Fabric3 Module requires Cisco NX-OS Software Release 5.2 or beyond
Performance/scalability
  • 8.4 Tbps internal switching bandwidth
  • Supported Fibre Channel port speeds
    • 1/2/4/8 Gbps autosensing, optionally configurable
    • 1/2/4 Gbps autosensing, optionally configurable
    • 10 Gbps fixed rate
  • Supported FCoE port speeds
    • 10 Gbps fixed rate
  • Supported Ethernet port speeds
    • 1 Gbps fixed rate
  • 32- and 48-port 8 Gbps Advanced Fibre Channel modules buffer credits:
    • 32 per port (shared-mode ports),
    • Up to 500 per port (dedicated-mode ports) standard
    • Up to 4095 on an individual port (dedicated-mode ports with optional Cisco MDS 9000 Enterprise Package license activated)
Advanced functionality
  • VSAN
  • Inter-VSAN Routing (IVR)
  • PortChannel with multipath load balancing
  • Flow-based, zone-based Quality of Service (QoS)
  • N_Port ID Virtualization (NPIV)
Reliability and availability
  • Online, nondisruptive software upgrades
  • Stateful, nondisruptive supervisor module failover
  • Hot-swappable redundant supervisor modules
  • Hot-swappable redundant crossbar modules
  • Hot-swappable redundant clock modules
  • Hot-swappable 1+1 redundant power
  • Hot-swappable fan trays with integrated temperature and power management
  • Hot-swappable Enhanced Small Form-Factor Pluggable (SFP+) optics (2/4/8/10 Gbps)
  • Hot-swappable small pluggable (X2) optics (10 Gbps)
  • Hot-swappable switching modules
  • Stateful process restart
  • Any-module, any-port configuration for PortChannels
  • Fabric-based multipathing
  • Per-VSAN fabric services
  • Online diagnostics
  • Port tracking
  • Virtual Routing Redundancy Protocol (VRRP) for management

Featured Content

Reliable, Scalable SAN Platform
Cisco MDS 9000 NX-OS Software Release 5.2 runs on Cisco MDS 9000 Switches.

Create an Ideal SAN
Gain intelligent, multilayer services that help fulfill your business needs

Additional Resources

Data Sheets and Literature

At-a-Glance

(All Cisco MDS 9500 Series Multilayer Directors At-a-Glance)

Cisco MDS 9000 Family 8-Gbps Advanced Fibre Channel Switching Modules (PDF - 440 KB)

Cisco MDS 9500 and 9700 Series Multilayer Directors (PDF - 380 KB)

Brochures

(All Cisco MDS 9500 Series Multilayer Directors Brochures)

Cisco MDS 9500 Series of Multilayer Directors

Data Sheets

(All Cisco MDS 9500 Series Multilayer Directors Data Sheets)

Cisco MDS 9000 10-Gbps 8-Port FCoE Module

Cisco MDS 9000 16-Port Storage Services Node

Cisco MDS 9000 18/4-Port Multiservice Module

Cisco MDS 9000 Family 4-Port 10-Gbps Fibre Channel Switching Module

Cisco MDS 9000 Family 8-Gbps Advanced Fibre Channel Switching Modules

Cisco MDS 9000 Family 8-Gbps Fibre Channel Switching Modules

Cisco MDS 9000 Family Pluggable Transceivers Data Sheet

Cisco MDS 9506 Multilayer Director Data Sheet

Cisco MDS 9509 Multilayer Director Data Sheet

Cisco MDS 9513 Multilayer Director Data Sheet

White Papers

(All Cisco MDS 9500 Series Multilayer Directors White Papers)

Advanced SAN Design Using Cisco MDS 9500 Series Multilayer Directors

Cisco MDS 9000 10-Gbps 8-Port FCoE Module (PDF - 280 KB)

Cisco MDS 9000 Family Investment Protection

High-Availability Storage Networks with Cisco MDS 9500 Series Multilayer Directors

Large SAN Design Best Practices

Miercom Report on Performance Tests for Cisco MDS 9509 and 9513 (PDF - 370 KB)
