THIS PRODUCT IS NO LONGER BEING SOLD AND MIGHT NOT BE SUPPORTED. READ THE END-OF-LIFE NOTICE TO LEARN ABOUT POTENTIAL REPLACEMENT PRODUCTS AND INFORMATION ABOUT PRODUCT SUPPORT.
The Cisco® Unified Communications system of voice and IP Communications products and applications helps organizations communicate more effectively-thereby helping them streamline business processes, reach the right resource the first time, and increase profitability. The Cisco Unified Communications portfolio is an integral part of the Cisco Business Communications Solution-an integrated solution for organizations of all sizes that also includes network infrastructure, security, and network management products; wireless connectivity; and a lifecycle services approach, along with flexible deployment and outsourced management options, end-user and partner financing packages, and third-party communications applications.
PRODUCT OVERVIEW
The Cisco MCS 7815-I2 Unified CallManager Appliance is an entry-level appliance for Cisco Unified CallManager 5.0 and is an integral part of a complete, scalable architecture for a new generation of high-quality IP Communications solutions for enterprise data networks. Delivering the high performance and availability that today's enterprise networks demand, the server appliance is easy to deploy and highly cost-effective. It is preinstalled with an operating system and the Cisco Unified CallManager 5.0 application. Fully operational upon startup, the server appliance requires entry of just a few configuration items such as IP address and domain. It includes the following features and components:
• Intel dual-core, Pentium D, 2.8-GHz (or higher) processor with an 800-MHz front side bus (FSB) and 1 MB of Layer 2 cache
• 2 GB of installed PC2-4200 memory, error correction code (ECC), Double Data Rate 2 (DDR2), synchronous dynamic RAM (SDRAM) standard; 8 GB maximum
• Single, integrated 10/100/1000BASE-T Gigabit Ethernet network-interface-card (NIC) port
• 80-GB serial-advanced-technology-attachment (SATA) hard disk drive
• No floppy diskette drive installed
• 400W autoranging, Power Factor Correction (PFC) power supply
• Tower form factor; 5 rack units (5RU) (8.5 in./21.6 cm high) if mounted in rack orientation using optional rack-mounting kit
PRODUCT SPECIFICATIONS
Table 1 gives specifications of the Cisco MCS 7815-I2 Unified CallManager Appliance.
Table 1. Specifications of Cisco MCS 7815-I2
Processor at Product Introduction
Processor (CPU)
Intel D dual core
Processor internal clock speed
2.8 GHz
Layer 2 cache
1024 KB
Maximum processors
1
Processors installed
1 (with 2 cores)
Basic input/output system (BIOS) type
Flash
Memory
Memory maximum
8 GB
Memory bus clock
533 MHz
Memory technology
PC2-4200 DDR2 SDRAM
Bit-error mitigation
Error checking and correction (ECC)
Total RAM slots
4
Memory installed
2 GB (2 x 1 GB)
Hard Disk
Hard disk installed
80 GB
Hard disk RPM
7200
Hard disk I/O transfer rate
1.5 Gbps
Hard disk average seek time
9 ms
Hard disk controller
I/O controller hub (ICH) SATA controller on planar
Network Connectivity
NIC
Single onboard 10/100/1000
Connector
One RJ-45 connector on rear of server
10BASE-T cable support
Category 3, 4, or 5 unshielded twisted-pair (UTP) (2 or 4 pair) up to 328 ft (100m)
100BASE-TX cable support
Category 5 UTP (2 pair) up to 328 ft (100m)
1000BASE-T cable support
Category 5 UTP, 5E UTP, or 6 UTP (2 pair) up to 328 ft (100m)
Interfaces
Ethernet
1
Serial ports
2
Parallel ports
1
Universal serial bus (USB) 2.0 ports
4 (2 at front and 2 at back of chassis)
Keyboard ports
1 PS/2
Mouse ports
1 PS/2
Audio ports
None
Interface Card Slots
Peripheral component interconnect (PCI) 2.2
2
PCI-X slots (64/100 MHz)
2
PCI-Express x8/x1
2
Security
• Power-on password (secured boot)
• A mechanical lock that allows the user to lock the system cover to prevent unauthorized personnel access to internal components of the server
• Selectable boot device sequence
• U-bolt tie-down security
Equipment Approvals and Safety
• FCC-Verified to comply with Part 15 of the Federal Communications Commission (FCC) Rules, Class B
• Canada Information Collection and Evaluation Standard (ICES)-003, issue 3, Class B
• UL/IEC 60950-1*
• CSA C22.2 No. 60950-1-03
• NOM-019*
Power
Maximum input power
400W
Autoranging AC mains input
Yes
PFC
Yes
Mains input frequency range
50 to 60 Hz
Input voltage low range
100 to 127 (nominal) VAC; 50-60 Hz; 8.0A (maximum)
Input voltage high range
200 to 240 (nominal) VAC; 50-60 Hz; 4.0A (maximum)
Input kVA approximate
• 0.106 kVA minimum
• 0.352 kVA maximum
Environmental
Air temperature-server on
50.0 to 95.0°F (10 to 35°C)
Air temperature-server off
-32 to 140°F (0 to 60.0°C)
Humidity-server on
8 to 80 percent
Maximum altitude
7000 ft (2133m)
BTU rating minimum
361 BTU per hour (106W)
BTU rating maximum
1201 BTU per hour (352W)
Sound emissions idle
5.0 bel
Sound emissions maximum
5.5 bel
Cooling system
2 fans installed
Dimensions
Form factor
Tower
Rack-mounting
5RU standard rack-mount with optional rack-mount kit ordered
Weight-maximum
45.8 lb (20.8 kg)
Height
17.25 in. (438.15 mm)
Width
8.5 in. (215.9 mm)
Depth
21.25 in. (539.75 mm)
* This server is certified by the respective UL and NOM agencies.
You may order the appliance in one of two ways. You can enter CALLMANAGER-5.0 into the Dynamic Configuration Tool on Cisco.com and view a list of Cisco MCS Unified CallManager Appliances and their associated licenses. You can also order the components individually using the following product part numbers:
• MCS7815I2-K9-CMA1
• LIC-CM5.0-7815-I2=
• KEY-CCM-ADMIN-K9= (order a minimum quantity of 2)
• DAT-USB-EXT-72= (optional external USB Digital Audio Tape [DAT] tape drive)
• DAT-USB-RM-72= (optional rack-mount USB DAT tape drive)
• DAT-USB-ADPT= (required if DAT-USB-EXT-72= or DAT-USB-RM-72= are used)
SERVER SPARES
To order spare servers, refer to Table 2.
Table 2. Ordering Information for Spare Server Appliance with Operating System and Cisco Unified CallManager 5.0
Application
Spare Part Number
Cisco Unified CallManager 5.0
MCS7815I2-K9-CMA1
FIELD-REPLACEABLE SPARES
To order spare parts for the servers, refer to Table 3.
Table 3. Ordering Information for Cisco MCS Unified CallManager Appliance Spare Parts
Spare Part Number
Description
MEM-7815-I2-2GB=
Spare 2 x 1-GB SDRAM dual in-line memory modules (DIMMs) for Cisco MCS 7815-I2 Unified CallManager Appliance
HDD-7815-I2-80=
Spare 80-GB SATA easy-swap hard disk drive
RAIL-7815-I2=
Rack-mounting rail kit for Cisco MCS 7815-I2
DAT-USB-EXT-72=
Spare external USB 36-/72-GB DAT drive
DAT-USB-RM-72=
Spare rack-mount USB 36-/73-GB DAT drive
DAT-USB-ADPT=(required for DAT-USB-EXT-72= or DAT-USB-RM-72=)
PCI-to-USB DAT adapter
IDENTIFYING CPU SPEED OF SERVER
As the Cisco MCS 7815-I2 matures and Intel replaces slower processors, the processor speeds will change. Table 4 provides the Cisco manufacturing part number shown on the chassis to help identify the processor speed of any individual server.
Table 4. Manufacturing Part Numbers by Processor Speed
Processor
Manufacturing Part Number Located on Server
Introduction
Intel dual-core, Pentium D, 2.8 GHz
74-4491-01
Initial production of server
SERVICE AND SUPPORT
Cisco Systems® offers a wide range of services programs to accelerate customer success. These innovative services programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you protect your network investment, optimize network operations, and prepare your network for new applications to extend network intelligence and the power of your business. For more information about Cisco services, refer to Cisco Technical Support Services orCisco Advanced Services.
