PRODUCT OVERVIEW
The Cisco® Media Convergence Server 7815-I2 (MCS 7815-I2) is an entry-level server platform for Cisco IP Communications solutions. An integral part of a complete, scalable architecture for a new generation of high-quality IP voice solutions that run on enterprise data networks, the Cisco MCS 7815-I2 is an easily deployed, cost-effective solution that delivers the high performance and availability demanded by today's enterprise networks. It offers the following features:
• Intel dual-core, Pentium D, 2.8-GHz (or higher) processor with an 800-MHz front side bus (FSB) and 1 MB of Layer 2 cache
• 2 GB of installed PC2-4200 memory, error correction code (ECC), Double Data Rate 2 (DDR2), synchronous dynamic RAM (SDRAM) standard; 8 GB maximum
• Single, integrated 10/100/1000BASE-T Gigabit Ethernet network-interface-card (NIC) port
• 80-GB serial-advanced-technology-attachment (SATA) hard disk drive
• No floppy diskette drive installed
• 400W auto-ranging, Power Factor Correction (PFC) power supply
• Tower form factor; 5 rack units (5RU) (8.5 in./21.6 cm high) if mounted in rack orientation using optional rack-mounting kit
SUPPORTED APPLICATIONS
The Cisco MCS 7815-I2 supports the following Cisco Systems® applications:
• Cisco Unified CallManager-Up to 300 IP phones
• Cisco Emergency Responder-Up to 6000 IP phones
• Cisco Unified Contact Center Express
• Cisco Unified IP Interactive Voice Response (IP IVR)
• Cisco Unified IP Queue Manager
• Cisco Unity® Unified Messaging-Up to 24 ports and 1000 mailboxes
• Cisco Unity Bridge-Up to 20 ports
KEY FEATURES AND BENEFITS
Performance
The Cisco MCS 7815-I2 is a robust, highly available server platform designed to support today's IP Communications applications. It uses a single Intel dual-core Pentium D, 2.8-GHz processor with an 800-MHz FSB.
Serviceability
Serviceable SATA Disk Drives
The Cisco MCS 7815-I2 is configured with one 80-GB SATA "cold-pluggable" disk drive, which is accessible to the end user through openings in the front bezel of the server. If a drive fails, the end user can schedule server downtime, power down the server, and replace the failed SATA drive by simply removing it (each drive is equipped with a front latch that positively mates the drive to the server) and replacing it with an unconfigured spare drive.
DAT Tape Drive Support
The Cisco MCS 7815-I2 can support a 36-/72-GB universal-serial-bus (USB) external Digital Audio Tape (DAT) drive (part number DAT-USB-EXT-72=) or an optional 36-/72-GB USB rack-mount DAT drive (part number DAT-USB-RM-72=). This tape drive connects through one of the USB 2.0 ports provided by the Cisco MCS 7815-I2 server.
PRODUCT SPECIFICATIONS
Table 1 gives specifications of the Cisco MCS 7815-I2.
Table 1. Specifications of Cisco MCS 7815-I2
Processor at Product Introduction
Processor (CPU)
Intel D dual core
Processor internal clock speed
2.8 GHz
Layer 2 cache
1024 KB
Maximum processors
1
Processors installed
1 (with 2 cores)
Basic input/output system (BIOS) type
Flash
Memory
Memory maximum
8 GB
Memory bus clock
533 MHz
Memory technology
PC2-4200 DDR2 SDRAM
Bit-error mitigation
Error Checking and Correction (ECC)
Total RAM slots
4
Memory installed
2 GB (2 x 1 GB)
Hard Disk
Hard disk installed
80 GB
Hard disk RPM
7200
Hard disk I/O transfer rate
1.5 Gbps
Hard disk average seek time
9 ms
Hard disk controller
I/O controller hub (ICH) SATA controller on planar
Hard disk type
SATA
Network Connectivity
NIC
Single onboard 10/100/1000
Connector
One RJ-45 connector on rear of server
10BASE-T cable support
Category 3, 4, or 5 unshielded twisted-pair (UTP) (2 or 4 pair) up to 328 ft (100m)
100BASE-TX cable support
Category 5 UTP (2 pair) up to 328 ft (100m)
1000BASE-T cable support
Category 5 UTP, 5E UTP, or 6 UTP (2 pair) up to 328 ft (100m)
Interfaces
Ethernet
1
Serial ports
2
Parallel ports
1
USB 2.0 ports
4 (2 at front and 2 at back of chassis)
Keyboard ports
1 PS/2
Mouse ports
1 PS/2
Audio ports
None
Interface Card Slots
Peripheral component interconnect (PCI) 2.2
2
PCI-X slots (64/100 MHz)
2
PCI-Express x8/x1
2
Security
• Power-on password (secured boot)
• A mechanical lock that allows the user to lock the system cover to prevent unauthorized personnel access to internal components of the server
• Selectable boot device sequence
• U-bolt tie-down security
Equipment Approvals and Safety
• FCC-Verified to comply with Part 15 of the Federal Communications Commission (FCC) Rules, Class B
• Canada Information Collection and Evaluation Standard (ICES)-003, issue 3, Class B
• UL/IEC 60950-1*
• CSA C22.2 No. 60950-1-03
• NOM-019*
Power
Maximum input power
400W
Autoranging AC mains input
Yes
PFC
Yes
Main input frequency range
50 to 60 Hz
Input voltage low range
100 to 127 (nominal) VAC; 50-60 Hz; 8.0A (maximum)
Input voltage high range
200 to 240 (nominal) VAC; 50-60 Hz; 4.0A (maximum)
Input kVA approximate
• 0.106 kVA minimum
• 0.352 kVA maximum
Environmental
Air temperature-server on
50.0 to 95.0°F (10 to 35°C)
Air temperature-server off
-32 to 140°F (0 to 60.0°C)
Humidity-server on
8 to 80 percent
Maximum altitude
7000 ft (2133m)
BTU rating minimum
361 BTU per hour (106W)
BTU rating maximum
1201 BTU per hour (352W)
Sound emissions idle
5.0 bel
Sound emissions maximum
5.5 bel
Cooling system
2 fans installed
Dimensions
Form factor
Tower
Rack-mounting
5RU standard rack-mount with optional rack-mount kit ordered
Weight-maximum
45.8 lb (20.8 kg)
Height
17.25 in. (438.15 mm)
Width
8.5 in. (215.9 mm)
Depth
21.25 in. (539.75 mm)
* This server is certified by the respective UL and NOM agencies.
Cisco Unified Contact Center Enterprise (admin workstation)
MCS-7815-I2-CCE1
Cisco Unified Contact Center Hosted (admin workstation)
MCS-7815-I2-CCE1
Cisco Unified Contact Center Express
MCS-7815-I2-CCX1
Cisco Unified IP IVR
MCS-7815-I2-CCX1
Cisco Personal Assistant
MCS-7815-I2-IPC1
Cisco Unified IP Queue Manager
MCS-7815-I2-CCX1
Cisco Unity Unified Messaging
MCS-7815-I2-ECS1
FIELD-REPLACEABLE SPARES
To order spare parts for the servers, refer to Table 4.
Table 4. Ordering Information for Server Spare Parts
Spare Part Number
Description
MEM-7815-I2-2GB=
Spare 2 x 1-GB SDRAM dual in-line memory modules (DIMMs) for Cisco MCS 7815-I2 server
HDD-7815-I2-80=
Spare 80-GB SATA Easy Swap hard disk drive
RAIL-7815-I2=
Rack-mounting rail kit for Cisco MCS 7815-I2
IDENTIFYING SERVER CPU SPEED
As the Cisco MCS 7815-I2 matures and Intel replaces slower processors, the processor speeds will change. Table 5 provides the Cisco manufacturing part number shown on the chassis to help identify the processor speed of any individual server.
Table 5. Manufacturing Part Numbers by Processor Speed
Processor
Manufacturing Part Number Located on Server
Introduction
Intel dual-core, Pentium D, 2.8 GHz
74-4484-01
Initial production of server
SERVICE AND SUPPORT
Cisco offers a wide range of services programs to accelerate customer success. These innovative services programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you protect your network investment, optimize network operations, and prepare your network for new applications to extend network intelligence and the power of your business. For more information about Cisco services, refer to Cisco Technical Support Services or Cisco Advanced Services.
