THIS PRODUCT IS NO LONGER BEING SOLD AND MIGHT NOT BE SUPPORTED. READ THE END-OF-LIFE NOTICE TO LEARN ABOUT POTENTIAL REPLACEMENT PRODUCTS AND INFORMATION ABOUT PRODUCT SUPPORT.
The Cisco® Unified Communications system of voice and IP communications products and applications enables organizations to communicate more effectively-enabling them to streamline business processes, reach the right resource the first time and impact the top and bottom line. The Cisco Unified Communications portfolio is an integral part of the Cisco Business Communications Solution-an integrated solution for organizations of all sizes which also includes network infrastructure, security, and network management products, wireless connectivity, and a lifecycle services approach, along with flexible deployment and outsourced management options, end-user and partner financing packages, and third-party communications applications.
PRODUCT OVERVIEW
The Cisco Media Convergence Server 7815-I1 (MCS-7815-I1) Unified CallManager Appliance is an entry-level appliance for Cisco Unified CallManager 5.0 and is an integral part of a complete, scalable architecture for a new generation of high-quality IP communications solutions for enterprise data networks. It delivers the high performance and availability that today's enterprise networks demand and represents a turnkey solution that is easy to deploy and highly cost-effective. The server appliance is preinstalled with an operating system and the Cisco Unified CallManager 5.0 application. The server appliance is fully operational upon startup, requiring entry of just a few configuration items such as IP address and domain. It includes the following features and components:
• Intel 3.06GHz or higher processors with 800 MHz front side bus (FSB) and 1 MB Layer 2 cache
• PC3200 CL3 error correction code (ECC) Double Data Rate (DDR) synchronous dynamic RAM (SDRAM) standard; 4GB SDRAM maximum
• Integrated Serial Advanced Technology Attachment (SATA) Controller
• 80GB SATA hard disk drive
• Single gigabit Ethernet port
PRODUCT SPECIFICATIONS
Table 1 lists the product specifications for the Cisco MCS7815I1-K9-CM50.
Table 1. Product Specifications
Processor at Product Introduction
Processor (CPU)
Intel Pentium 4
Processor Internal Clock Speed
3060MHz
Layer 2 Cache
1024KB
Maximum Processors
1
Processors Installed
1
Basic Input/Output System (BIOS) Type
Flash
Memory
Memory Maximum
4GB
Memory Bus Clock
200MHz
Memory Technology
PC3200 DDR SDRAM
Total RAM Slots
4
Memory Installed
2GB
Hard Disk
Hard Disk Installed
80GB SATA
Hard Disk RPM
7200
Hard Disk Average Seek Time
< 9 ms
Hard Disk Controller
I/O Controller Hub (ICH)-S SATA controller on motherboard
Hard Disk Type
Serial-ATA Easy Swap
Network Connectivity
Network Interface Card (NIC)
Single onboard 10/100/1000
Connector
One RJ-45 connector on rear of server
10BASE-T Cable Support
Categories 3, 4, or 5 unshielded twisted-pair (UTP) (2 or 4 pair) up to 328 feet (100 meters)
100BASE-TX Cable Support
Category 5 UTP (2 pair) up to 328 feet (100 meters)
1000BASE-T Cable Support
Category 5 UTP, 5E UTP, 6 UTP (2 pair) up to 328 feet (100 meters)
Interfaces
Serial Ports
2
Parallel Ports
1
Universal Serial Bus (USB) 2.0 Ports
4
Keyboard Ports
1 PS2
Mouse Ports
1 PS2
Audio Ports
None
Interface Card Slots
Peripheral Component Interconnect (PCI) 2.2 Full Length Slots (32/33 MHz)
You may order the appliance in one of two ways. You can enter CALLMANAGER-5.0 into the Dynamic Configuration Tool on Cisco.com and view a list of Cisco MCS Unified CallManager Appliances and their associated licenses. You can also order the components individually using the following product IDs:
• MCS7815I1-K9-CM50
• LIC-CM5.0-K9-7815-I1=
• KEY-CCM-ADMIN-K9= (order a minimum quantity of 2)
SERVER SPARES
To order spare servers, refer to Table 2.
Table 2. Ordering Information for Spare Server Appliance with Operating System and Cisco Unified CallManager 5.0
Application
Spare Part Number
Cisco Unified CallManager 5.0
MCS7815I1-K9-CM50
FIELD REPLACEABLE SPARES
To order spare parts for the servers, refer to Table 3.
Table 3. Ordering Information for Server Appliance Spare Parts
Description
Spare Part Number
Spare 512 MB SDRAM Dual In-Line Memory Module (DIMM) for Cisco MCS 7815-I1 Server
MEM-7815-I1-512=
Spare 1GB SDRAM Dual In-Line Memory Module (DIMM) for Cisco MCS 7815-I1 Server
MEM-7815-I1-1GB=
Spare 80 GB SATA Easy Swap Hard Disk Drive
HDD-7815-I1-80=
Rack-Mounting Rail Kit for Cisco MCS 7815-I1
RAIL-7815-I1=
IDENTIFYING CPU SPEED OF SERVER
As the Cisco MCS 7815I1-K9-CM50 matures and Intel replaces slower processors, the processor speeds will change. Table 4 provides the Cisco manufacturing part number that will be shown on the chassis to help identify any processor speed of any individual server appliance.
Table 4. Manufacturing Part Numbers by Processor Speed
Processor
Manufacturing Part Number Located on Server
Introduction
Intel Pentium 4 3.06GHz
74-4385-01
Initial production of server appliance
CISCO UNIFIED COMMUNICATIONS SERVICES AND SUPPORT
Using the Cisco Lifecycle Services approach, Cisco Systems® and its partners offer a broad portfolio of end-to-end services to support the Cisco Unified Communications system. These services are based on proven methodologies for deploying, operating, and optimizing IP communications solutions. Upfront planning and design services, for example, can help you meet aggressive deployment schedules and minimize network disruption during implementation. Operate services reduce the risk of communications downtime with expert technical support. Optimize services enhance solution performance for operational excellence. Cisco and its partners offer a system-level service and support approach that can help you create and maintain a resilient, converged network that meets your business needs.
