PRODUCT OVERVIEW
The Cisco Media Convergence Server 7825-H1 Unified CallManager Appliance (MCS 7825-H1) is an integral part of a complete, scalable architecture for a new generation of high-quality IP communications solutions that operate on enterprise data networks. This powerful platform is a turnkey solution that is easy to deploy and highly cost-effective, and it delivers the high performance and availability that today's enterprise networks demand. The server appliance is preinstalled with an operating system and the Cisco Unified CallManager 5.0 application. The server appliance is fully operational upon startup, requiring entry of just a few configuration items such as IP address and domain. The Cisco MCS 7825-H1 Unified CallManager Appliance includes the following features and components:
• Intel Pentium 4 3.4GHz processor, a 800MHz front side bus (FSB), and 1MB of Layer 2 cache
• PC3200 double-data-rate-1 (DDR1) 400MHz RAM
• Two gigabit network interface cards (NICs)
• Two 80-GB serial advanced technology attachment (ATA) hard-disk drives configured in Redundant Array of Independent Disks (RAID) 1
• Quick-deployment third-party rail kit
• 350 W power-factor-correction (PFC) power supply
• 1 RU (1.75-in.) form factor
• Integrated Lights Out (ILO) remote management
SUPPORTED APPLICATIONS
The Cisco MCS 7825-H1 Unified CallManager Appliance supports up to 1000 IP phones per server and 4000 IP phones per cluster.
KEY FEATURES AND BENEFITS
Performance
The Cisco MCS 7825-H1 Unified CallManager Appliance is a robust, highly available server platform designed to support Cisco Unified CallManager 5.0 using a single Intel Pentium 4 3.4 GHz processor with an 800 MHz FSB.
Serviceability
System-Health LEDs
The Cisco MCS 7825-H1 Unified CallManager Appliance provides system-health LEDs and unit-identification lights on the front and back of the server to ease the identification of system issues. When an internal component fails, this indication is made on an internal-component LED (amber) and on the front panel of the Cisco MCS 7825-H1 Unified CallManager Appliance. If the item is serviceable by removing the hood, as in the case of a fan failure, the internal-health LED illuminates. If no failures have occurred, the system-health LED is green. If the failure is critical and has caused the system to shut down, the LED is red.
Redundant ROM
In the Cisco MCS 7825-H1 Unified CallManager Appliance, the ROM is divided into two logical parts. When the system boots, the primary ROM side is executed and used in server operation. During a ROM flash, the backup side is flashed. When the flash is fully completed, the backup side becomes the primary. If under rare conditions the flash does not complete safely, potentially because of a power interruption, the backup is available to boot the system. In the situation where both images are valid, the user can select which image to use at boot time.
Serviceable SATA Disk Drives
The Cisco MCS 7825-H1 Unified CallManager Appliance is configured with two 80-GB serial advanced technology attachment (SATA) "cold-pluggable" disk drives configured in a RAID 1 mirror set. The appliance continues to operate if either of the two disk drives fails. The SATA disk drives are accessible to the end user through openings in the front bezel of the server. If a drive fails, the end user can schedule server downtime, power down the server, and replace the failed SATA drive by simply removing it (each drive is equipped with a front latch that positively mates the drive to the server) and replacing it with an unconfigured spare drive. After restarting the server, the RAID 1 firmware initiates a re-mirroring of the new drive to help ensure that drive redundancy on the Cisco MCS 7825-H1 Unified CallManager Appliance is maintained. The serial-drive technology introduced in the Cisco MCS 7825-H1 Unified CallManager Appliance provides a highly reliable, high-performance, cost-effective solution.
PRODUCT SPECIFICATIONS
Table 1 gives specifications of the Cisco MCS 7825-H1 Unified CallManager Appliance.
You may order the appliance in one of two ways. You can enter CALLMANAGER-5.0 into the Dynamic Configuration Tool on Cisco.com and you will view a list of Cisco Unified CallManager appliances and their associated licenses. You may also order the components individually using the following product IDs:
• MCS7825H1-K9-CM50
• LIC-CM5.0-K9-7825-H1=
• KEY-CCM-ADMIN-K9= (order a minimum quantity of 2)
APPLIANCE SPARES
To order spare appliances reference the table below.
Table 2. Ordering Information for Spare Appliances
Application
Spare Part Number
Cisco Unified CallManager 5.0
MCS7825H1-K9-CM50
FIELD-REPLACEABLE SPARES
To order spare parts for the servers reference the table below.
Table 3. Ordering Information for Server Spare Parts
Spare Part Number
Description
MEM-7825-H1-512=
Spare 512MB SDRAM dual in-line memory module (DIMM) for Cisco MCS 7825-H1 server
MEM-7825-H1-1GB=
Spare 1GB SDRAM dual in-line memory module (DIMM) for Cisco MCS 7825-H1 server
HDD-7825-H1-80=
Spare 80GB SATA hard-disk drive, cold-pluggable
IDENTIFYING SERVER CPU SPEED
As the Cisco MCS 7825-H1 matures, the processor speeds will be changed as Intel retires slower processors and replaces them with faster processors. Table 4 provides the Cisco manufacturing part number that is shown on the chassis to help identify any processor speed of any individual server.
Table 4. Manufacturing Part Numbers by Processor Speed
Processor
Manufacturing Part Number Located on Server
Introduction
Intel Pentium 4 3.4 GHz
74-4386-01
Initial production of server
