THIS PRODUCT IS NO LONGER BEING SOLD AND MIGHT NOT BE SUPPORTED. READ THE END-OF-LIFE NOTICE TO LEARN ABOUT POTENTIAL REPLACEMENT PRODUCTS AND INFORMATION ABOUT PRODUCT SUPPORT.
PRODUCT OVERVIEW
The Cisco® Media Convergence Server 7815-I1 (MCS 7815-I1) is an entry level server platform for Cisco IP Communications solutions. The Cisco MCS 7815-I1 is an integral part of a complete, scalable architecture for a new generation of high-quality IP voice solutions that run on Enterprise data networks. Cisco MCS 7815-I1 delivers the high performance and availability demanded by today's enterprise networks and represents a turnkey solution that is easy to deploy and highly cost-effective. The following points are an outline of the features of Cisco MCS 7815-I1:
• Intel 3.06GHz or higher processors with 800 MHz front side bus (FSB) and 1 MB Layer 2 cache
• PC3200 CL3 error correction code (ECC) Double Data Rate (DDR) synchronous dynamic RAM (SDRAM) standard; 4GB SDRAM maximum
• Integrated Serial Advanced Technology Attachment (SATA) Controller
• 80GB SATA hard disk drive
• Single gigabit Ethernet port
FLEXIBILITY
The Cisco MCS 7815-I1 can run any of the following Cisco Systems® applications:
• Cisco CallManager-Up to 300 IP phones
• Cisco Emergency Responder-Up to 6000 IP Phones
• Cisco IP Contact Center Express Edition
• Cisco IP Interactive Voice Response (IP IVR)
• Cisco IP Queue Manager
• Cisco Unity™-Up to 24 ports and 1000 mailboxes
• Cisco Unity Bridge-Up to 20 ports
PRODUCT SPECIFICATIONS
Table 1 lists the product specifications for the Cisco MCS 7815-I1.
Table 1. Product Specifications
Processor at Product Introduction
Processor (CPU)
Intel Pentium 4
Processor internal clock speed
3060MHz
Layer 2 cache
1024KB
Maximum processors
1
Processors installed
1
Basic input/output system (BIOS) type
Flash
Memory
Memory maximum
4GB
Memory bus clock
200MHz
Memory technology
PC3200 DDR) SDRAM
Total RAM slots
4
Memory Installed
1GB (2x512) MCS-7815-I1-ECS1
2GB (2x1GB) MCS-7815-I1-IPC3
2GB (2x1GB) MCS-7815-I1-CC2
Hard Disk
Hard disk installed
80GB SATA
Hard disk RPM
7200
Hard disk average seek time
< 9 ms
Hard disk controller
I/O Controller Hub (ICH)-S SATA controller on motherboard
Hard disk type
Serial-ATA Easy Swap
Network Connectivity
Network interface card (NIC)
Single onboard 10/100/1000
Connector
One RJ-45 connector on rear of server
10BASE-T cable support
Categories 3, 4, or 5 unshielded twisted-pair (UTP) (2 or 4 pair) up to 328 feet (100 meters)
100BASE-TX cable support
Category 5 UTP (2 pair) up to 328 feet (100 meters)
1000BASE-T cable support
Category 5 UTP, 5E UTP, 6 UTP (2 pair) up to 328 feet (100 meters)
Interfaces
Serial ports
2
Parallel ports
1
Universal serial bus (USB) 2.0 ports
4
Keyboard ports
1 PS2
Mouse ports
1 PS2
Audio ports
None
Interface Card Slots
Peripheral component interconnect (PCI) 2.2 full length slots (32/33 MHz)
Table 3. Ordering Information for Spare Servers by Application
Application
Spare Part Number
Cisco CallManager
MCS-7815-I1-IPC3
Cisco Emergency Responder
MCS-7815-I1-IPC3
Cisco IPCC Express
MCS-7815-I1-CC2
Cisco IP IVR
MCS-7815-I1-CC2
Cisco Personal Assistant
MCS-7815-I1-IPC3
Cisco Unity
MCS-7815-I1-ECS1
FIELD REPLACEABLE SPARES
To order spare parts for the servers, refer to Table 4.
Table 4. Ordering Information for Server Spare Parts
Description
Spare Part Number
Spare 512 MB SDRAM dual in-line memory module (DIMM) for Cisco MCS 7815-I1 server
MEM-7815-I1-512=
Spare 1GB SDRAM dual in-line memory module (DIMM) for Cisco MCS 7815-I1 server
MEM-7815-I1-1GB=
Spare 80 GB SATA Easy Swap hard disk drive
HDD-7815-I1-80=
Rack-mounting Rail Kit for Cisco MCS 7815-I1
RAIL-7815-I1=
IDENTIFYING CPU SPEED OF SERVER
As the Cisco MCS 7815-I1 matures and Intel replaces slower processors, the processor speeds will change. Table 5 provides the Cisco manufacturing part number that will be shown on the chassis to help identify any processor speed of any individual server.
Table 5. Manufacturing Part Numbers by Processor Speed
Processor
Manufacturing Part Number Located on Server
Introduction
Intel Pentium 4 3.06GHz
74-3526-01
Initial production of server
MCS-7815-I1-CC1
MCS-7815-I1-IPC1
MCS-7815-I1-IPC2
MCS-7815-I1-ECS1
Intel Pentium 4 3.06GHz
74-4132-01
Increased memory server
MCS-7815-I1-CC2
MCS-7815-I1-IPC3
SERVICE AND SUPPORT
Cisco offers a wide range of services programs to accelerate customer success. These innovative services programs are delivered through a unique combination of people, processes, tools, and partners, resulting in high levels of customer satisfaction. Cisco services help you to protect your network investment, optimize network operations, and prepare the network for new applications to extend network intelligence and the power of your business. For more information about Cisco Services, see Cisco Technical Support Services or Cisco Advanced Services.
WARRANTY INFORMATION
Cisco offers a one-year limited hardware warranty on Cisco Media Convergence Servers. For terms and conditions of this warranty, refer to http://www.cisco.com/univercd/cc/td/doc/es_inpck/1y1cen__.htm.
