DATA SHEET
As the market leader in true IP Telephony, Cisco continues to deliver unsurpassed end-to-end data and VoIP solutions, offering the most complete, stylish, fully featured Cisco Unified IP Phone portfolio to enterprise and small-to-medium sized customers. Cisco Unified IP phones provide unmatched levels of integrated business functionality and converged communications features beyond today's conventional voice systems.
Figure 1. Cisco Unified IP Phone 7910G+SW
The Cisco Unified IP Phone 7910G+SW brings state-of-the-art technology to voice communication solutions. The Cisco Unified IP Phone 7910G+SW is a basic telephone designed primarily for common-use areas-such as lobbies, break rooms, and hallways-that do not require specialized features. The Cisco Unified IP Phone 7910G+SW includes a two-port Cisco switch making it also suitable for worker applications requiring basic phone functionality, including a co-located Ethernet device, such as a PC.
This single-line phone also provides four dedicated feature buttons, line, hold, transfer, and settings, located prominently under the display. A cluster of six feature access keys is located above the volume control rocker switch. The factory default configuration for messages (msgs), conference (conf), forward, speed dial (speed 1, speed 2), and redial can be programmed by a system administrator to perform other functions, such as Call Park, Call Pick-Up, and Night Service, as well as additional speed dials and other traditional telephone features.
THE CISCO UNIFIED IP PHONE 7910G+SW: BASIC IP PHONE FUNCTIONALITY
The Cisco Unified IP Phone 7910G+SW provides a 2x24 character LCD display. The display provides features such as date and time, calling party name, calling party number, and digits dialed, as well as call state indicators, a settings menu, and other information.
This phone does not include two-way speakerphone capability but features on-hook dialing and call monitor mode. The phone also has a mute button for the handset/headset microphones. A rocker switch for controlling volume for ringer, handset, and call monitor is also provided. The user can lock these volumes by pressing the Settings key followed by the Save key. In the Services menu, users can also select two ringer types and set the LCD contrast using the volume buttons.
Figure 2. Cisco Unified IP Phone 7910G+SW
Icon buttons
The Cisco Unified IP Phone 7910G+SW plugs into a standard RJ-45 Ethernet connection and has a two-port switch with 10/100BASE-T interface. This provides single RJ-45 connection at the desktop for the phone and an additional LAN device such as a PC.
The footstand of the Cisco Unified IP Phone 7910G+SW is adjustable from flat to 60 degrees to provide optimum viewing of the display and comfortable use of all buttons and keys.
TECHNICAL SPECIFICATIONS
Hearing-aid-compatible (HAC) handset with ADA-compliant volume
G.711 and G.729a audio compression
Dynamic Host Configuration Protocol (DHCP) is supported
Comfort noise generation and voice activity detection (VAD) programming on a system basis
7910 models are compatible with CallManager version 3.0(5) or higher
CallManager Software license is required.
PHYSICAL SPECIFICATIONS
Dimensions: 8 1/4 x 10.1/2 x 6 in. (20.32 x 26.67 x 15.24 cm) (H x W x D)
Weight: 2.2 lb (1.0 kg)
The 7910G+SW has two standard 10/100 BASE-T RJ-45 jacks.
48 VDC required; can be provided down the LAN using Cisco Discovery Protocol (CDP), or can be supplied locally at the desktop using an optional AC to DC power supply, CP-PWR-CUBE-3=. This power cube also requires ordering one of the AC country cords below.
AC Country Power Cords
CP-PWR-CORD-AP= (Asia Pacific)
CP-PWR-CORD-AR= (Argentina)
CP-PWR-CORD-AU= (Australia)
CP-PWR-CORD-CE= (Central Europe)
CP-PWR-CORD-JP= (Japan)
CP-PWR-CORD-NA= (North America)
CP-PWR-CORD-SW= (Switzerland)
CP-PWR-CORD-UK= (United Kingdom)
Temperature
Operating temperature: 32° F to 104° F (0 to 40 C)
Relative humidity: 10% to 95% (noncondensing)
Storage temperature: 14° F to 140° F (-10 to 60 C)
Certification
Regulatory Compliance
Products bear CE Marking
Safety
UL-1950
EN 60950
CSA-C22.2 No. 950
IEC 60950
AS/NZS 3260
TS 001
Electro Magnetic Coupling
FCC Part 15 (CFR 47) Class B
ICES-003 Class B
EN55022 Class B
CISPR22 Class B
AS/NZS 3548 Class B
VCCI Class B
EN55024
EN50082-1
EN61000-3-2
EN61000-3-3
Telecom
FCC Part 68 (CFR47) (HAC)
ORDERING INFORMATION FOR CISCO UNIFIED IP PHONE 7910G+SW
|
Part Number
|
Description
|
|
CP-7910G+SW
|
Cisco Unified IP Phone 7910G+SW
|
|
CP-7910G+SW-CH1
|
Cisco Unified IP Phone 7910G+SW, channel with license
|
Note: All Cisco Unified IP phones require the purchase of a phone technology license, regardless of call protocol being used.
ACCESSORIES ORDERING INFORMATION
Optional wall mount kits are available in both locking and non-locking versions:
• CP-LCKNGWALLMOUNT=
• CP-WALLMOUNTKIT=
