This product bulletin details changes to the Cisco IOS® Software packaging for Cisco® 2800 Series routers. It introduces four new cross-platform feature sets in Cisco IOS Software releases 12.4 Mainline and 12.4T.
Note: This product bulletin covers the packaging of functions into feature sets. It does not cover individual new features. For information about new features in Cisco IOS Software releases 12.4 Mainline and 12.4T, refer to the Cisco IOS Software pages at Cisco.com.
OVERVIEW
The Cisco 2800 and 3800 series integrated services routers are introduced exclusively on eight cross-platform feature sets. Similar to 12.3T, Cisco IOS Software releases 12.4 Mainline and 12.4T consist exclusively of the cross-platform feature sets.
Table 1. Type of Feature Sets by Release Train
Cisco IOS Software Release 12.3 Mainline
Cisco IOS Software Release 12.3T
Cisco IOS Software Releases 12.4 Mainline and 12.4T
Classic Feature Sets
Cross-Platform Feature Sets
Cross-Platform Feature Sets
Cross-Platform Feature Sets
Special-Purpose Feature Sets
Special-Purpose Feature Sets
Special-Purpose Feature Sets
In addition to the eight cross-platform feature sets that were released with Cisco IOS Software releases 12.3T and 12.3 Mainline, four additional cross-platform feature sets will be added starting with 12.4 Mainline and 12.4T. Derivatives of the existing eight feature sets, these four new feature sets were created to address router management capabilities. The new feature sets are described in Table 2.
Table 2. New Feature Sets for Cisco IOS Software Releases 12.4 and 12.4T
Image Name
Cisco IOS Software Release 12.3 and Prior
Image Name
Cisco IOS Software Release 12.4 and Forward
IP Base
New
IP Base
X
IP Base without Crypto
Renamed
Enterprise Base
New
Enterprise Base
X
Enterprise Base without Crypto
Renamed
IP Voice
New
IP Voice
X
IP Voice without Crypto
Renamed
Advanced Security
X
Advanced Security
X
SP Services
X
SP Services
X
Advanced IP Services
X
Advanced IP Services
X
Enterprise Services without Crypto
New
Enterprise Services
X
Enterprise Services
X
Advanced Enterprise Services
X
Advanced Enterprise Services
X
Note that there is a name change for the feature sets that previously had no cryptography technology, and this fact is now noted in their titles. Going forward, the new feature sets that have cryptography technology will have the basic title without any cryptography designator.
Figure 1. Reformation Feature Map
The remainder of this product bulletin provides details of feature set availability in Cisco IOS Software releases 12.4 Mainline and 12.4T.
CISCO IOS SOFTWARE RELEASE 12.4 MAINLINE
Overview of Available Feature Sets in Cisco IOS Software Release 12.4 Mainline
Table 3 lists the Cisco IOS Software Release 12.4 Mainline feature sets that are available for the Cisco 2800 Series routers.
Note that the flash memory recommendations given in the table are calculated without added management tools such as Cisco Security Device Manager (SDM).
Table 3. Cisco 2801-12.4M Feature Set Memory Recommendations
Software Product Description
Product ID
Product Description
Image Filename
Recommended Flash 12.4M
Recommended DRAM 12.4M
S280AESK9
Cisco 2800 IOS ADVANCED ENTERPRISE SERVICES
c2801-adventerprisek9-mz
64
128
S280AISK9
Cisco 2800 IOS ADVANCED IP SERVICES
c2801-advipservicesk9-mz
64
128
S280ASK9
Cisco 2800 IOS ADVANCED SECURITY
c2801-advsecurityk9-mz
64
128
S280EB
Cisco 2800 IOS ENTERPRISE BASE WITHOUT CRYPTO
c2801-entbase-mz
64
128
S280EBK9
Cisco 2800 IOS ENTERPRISE BASE
c2801-entbasek9-mz
64
128
S280ES
Cisco 2800 IOS ENTERPRISE SERVICES WITHOUT CRYPTO
c2801-entservices-mz
64
128
S280ESK9
Cisco 2800 IOS ENTERPRISE SERVICES
c2801-entservicesk9-mz
64
128
S280IPB
Cisco 2800 IOS IP BASE WITHOUT CRYPTO
c2801-ipbase-mz
64
128
S280IPBK9
Cisco 2800 IOS IP BASE
c2801-ipbasek9-mz
64
128
S280IPV
Cisco 2800 IOS IP VOICE WITHOUT CRYPTO
c2801-ipvoice-mz
64
128
S280IPVK9
Cisco 2800 IOS IP VOICE
c2801-ipvoicek9-mz
64
128
S280SPSK9
Cisco 2800 IOS SP SERVICES
c2801-spservicesk9-mz
64
128
Table 4. Cisco 2811-2851-12.4M Feature Set Memory Recommendations
Cisco 2800 IOS ADVANCED ENTERPRISE SERVICES WITH SNA SWITCHING
c2800nm-adventerprisek9_sna-mz
64
256
S28NAISK9
Cisco 2800 IOS ADVANCED IP SERVICES
c2800nm-advipservicesk9-mz
64
256
S28NASK9
Cisco 2800 IOS ADVANCED SECURITY
c2800nm-advsecurityk9-mz
64
256
S28NEB
Cisco 2800 IOS ENTERPRISE BASE WITHOUT CRYPTO
c2800nm-entbase-mz
64
256
S28NEBK9
Cisco 2800 IOS ENTERPRISE BASE
c2800nm-entbasek9-mz
64
256
S28NES
Cisco 2800 IOS ENTERPRISE SERVICES WITHOUT CRYPTO
c2800nm-entservices-mz
64
256
S28NESK9
Cisco 2800 IOS ENTERPRISE SERVICES
c2800nm-entservicesk9-mz
64
256
S28NIPB
Cisco 2800 IOS IP BASE WITHOUT CRYPTO
c2800nm-ipbase-mz
64
256
S28NIPBK9
Cisco 2800 IOS IP BASE
c2800nm-ipbasek9-mz
64
256
S28NIPV
Cisco 2800 IOS IP VOICE WITHOUT CRYPTO
c2800nm-ipvoice-mz
64
256
S28NIVS
Cisco 2800 IOS IP VOICE WITH INTEGRATED VOICE/VIDEO GATEKEEPER, IP-IP GATEWAY, TDM-IP GATEWAY
c2800nm-ipvoice_ivs-mz
64
256
S28NIPVK9
Cisco 2800 IOS IP VOICE
c2800nm-ipvoicek9-mz
64
256
S28NSPSK9
Cisco 2800 IOS SP SERVICES
c2800nm-spservicesk9-mz
64
256
Feature Area Map for Cisco IOS Software Release 12.4 Cross-Platform Feature Sets
The cross-platform feature sets are tailored to ease the choice of feature sets in a multiplatform environment. They were initially available for Cisco 1700 Series and Cisco 2600XM, 2691, 3725, and 3745 routers and are now also available for the Cisco 1800, 2800, and 3800 series routers. The cross-platform feature sets simplify the image selection process by providing similar functions across platform boundaries.
