The Cisco TelePresence™ EX Series transforms the workplace by combining work, communications, and collaboration-all on the desktop with just the touch of a finger.
The EX Series is an all-in-one tool that streamlines the desktop so you can fluidly move from individual work on your laptop, to a quick video call with a colleague, to problem-solving over shared spreadsheets. Tight integration with Cisco Unified Communications Manager also provides EX Series users with powerful video and voice functionality. The series comprises the EX90 and the EX60: The EX90 is designed for the team leader or manager for immediate presence with customers, partners, and employees, while the EX60 can be scaled throughout the organization, designed especially for the knowledge worker or individual contributor.
The EX Series is part of the broad portfolio of Cisco TelePresence systems offering immersive, multipurpose, and personal endpoints to meet the needs of organizations of all sizes. Cisco TelePresence technology powers the new way of working where everyone, everywhere can be more productive through face-to-face collaboration.
Features and Benefits
• A high-quality screen with clear high-definition (HD) resolution enables a transparent, all-in-one device to work, meet, and collaborate (24" or 21.5").
• Video resolutions of 1080p30 and 720p60 bring the Cisco TelePresence experience to the desk.
• Integration with Cisco Unified Communications Manager enables rich features including voicemail indicator, single number reach, and ad-hoc conferencing.
• The Cisco TelePresence Touch 8 user interface allows for simple control.
• Collaboration is natural with transparent one-touch sharing of high-definition content and a built-in document camera.
• A Cisco TelePresence PrecisionHD camera enables video clarity and optimal F1.7, 45-65° or 50° field of view.
• H.323 and Session Initiation Protocol (SIP) with bandwidth up to 6 Mbps point-to-point provide the possibility to establish calls with very high quality.
• Dual front speakers offer superior audio, including an integrated subwoofer on the EX90.
• A wideband handset is included; you can also add a headset input for privacy (wired or Bluetooth wireless).
• The EX90 supports embedded MultiSite which brings together up to four locations into one call.
• Dual display capability (HDMI out) is also available on the EX90 to enable a second display that can be dedicated to content.
• The system is standards-based for immediate connectivity to anyone regardless of system, from a soft client to immersive telepresence system, to a meeting room around the globe.
Product Specifications
Table 1 lists the physical specifications; Table 2 gives video and audio specifications; and Table 3 gives network, security, and management specifications of the Cisco TelePresence EX Series.
Table 1. Product Specifications
Product Compatibility
Fully compatible with standards-compliant telepresence and video systems
Software Compatibility
Cisco TelePresence Software Version TC3.1 (EX90) and TC4.0 (EX60) or later, or TE 6.0
Components
Fully integrated unit including:
• Codec
• Display
• Camera
• Microphone and speakers
• Cables including: VGA-to-DVI-I cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable
Display
• EX90
• 24-in. LCD monitor
• Resolution: 1920 x 1200 (16:10)
• Contrast ratio: 1000:1
• Viewing angle: 160°
• Response time: 5 ms
• Brightness: 300cd/m2
• 5°-15° tilt
• EX60
• 21.5-in. LCD monitor (with LED backlight)
• Resolution: 1920 x 1080 (16:9)
• Contrast ratio: 1000:1
• Viewing angle: 170°
• Response time: 5 ms
• Brightness: 225cd/m2
• 5°-15° tilt
PC and second-source video input
DVI-I
EX90: HDMI in
Supported PC input resolutions
EX90: SVGA (800 x 600) to WUXGA (1920 x 1200)
EX60: SVGA (800 x 600) to 1080p (1920 x 1080)
Camera
• Cisco TelePresence PrecisionHD design
• Resolutions: 1080p30 and 720p60
• Auto focus
• Integrated privacy shutter
• Document camera mode
• Multicoated all-glass optics
• 1/3-in., 2.1 megapixel CMOS sensor
EX90
• Horizontal field of view: 45°-65°
• Vertical field of view: 40°-27°
• Focus distance 0.3-infinity
• Optical, motorized zoom
EX60
• Horizontal field of view: 50°
• Vertical field of view: 29°
• Focus distance 0.1-infinity
Audio system
• Two stereo front speakers
• Integrated full-range microphone
• One 3.5-mm line-in jack for PC or other audio source
• Two 3.5-mm jack for headset
• Wideband handset
• Bluetooth module 2.1 + EDR
• Integrated subwoofer (EX90 only)
• Support for Cisco TelePresence Table Microphone 20 (EX90 only)
• Support for the Cisco TelePresence Management Suite
• Total management through embedded Simple Network Management Protocol (SNMP), Telnet, SSH, XML, and Simple Object Access Protocol (SOAP)
• Remote software upload: Through web server, Secure Copy Protocol, HTTP, and HTTPS
Directory services
• Support for local directories (My Contacts)
• Corporate directory
• Unlimited entries using server directory supporting
• Lightweight Directory Access Protocol (LDAP) and H.350
• Unlimited number for corporate directory (available with Cisco TelePresence Management Suite
• Local directory: 200 numbers
• Received calls with date and time
• Placed calls with date and time
• Missed calls with date and time
Ordering Information
To place an order, please contact your Cisco representative.
Table 4. Ordering Information
Product Name
Part Number
Compliance Model Number
Cisco TelePresence EX90
CTS-EX90-K9
TTC7-19
Comes with: EX90 unit and camera, C-series Natural Presenter Package option, Cisco TelePresence Touch 8
Ordering Options for the Cisco TelePresence EX90
MultiSite option for Cisco TelePresence EX90
LIC-EX90-MS
Premium Resolution option for Cisco TelePresence EX90
LIC-EX90-PR
Dual-display option for Cisco TelePresence EX90
LIC-EX90-DD
Cisco TelePresence EX60
CTS-EX60-K9
TTC7-20
Comes with: EX60 unit and camera, C-series Natural Presenter Package option, Cisco TelePresence Touch 8
Ordering Options for the Cisco TelePresence EX60
Premium resolution option for Cisco TelePresence EX60
LIC-EX60-PR
