Cisco License Manager

Feature

Description and Benefit

Autodiscovery and building of an inventory of licensed features

Automatically discovers all devices with license enforcement capabilities. In addition

Enhanced device and PAK search capabilities and management

Cisco License Manager provides users with enhanced and faster search capabilities in the list of devices and list of PAKs and highlights the matches to effectively manage devices and PAKs. In addition

Enhanced security and virtualization

Cisco License Manager user-security model supports role-based access control and provides the following five user roles:

Cisco License Manager allows you to restrict access to managed devices and PAKs through access control lists for each user. With this feature, you can virtualize one Cisco License Manager installation into multiple user views. Cisco License Manager can be deployed in the VMware ESX Server 3 Virtual Machine environment.

Obtain licenses from Cisco.com

With a Cisco supplied PAK, you can associate feature SKUs with devices and securely connect to the Cisco.com license server to automatically get license keys. This reduces the complexity associated with software activation. You can also obtain licenses for predeployed or offline devices. Cisco License Manager resides at the customer premises and has access to the customer network and needs Internet connectivity to Cisco.com for many of its features. For isolated networks, it supports two-stage license deployment where customers can move Cisco License Manager to a network domain with Internet connectivity and obtain and save licenses to its database by securely communicating with the license server at Cisco.com. Cisco License Manager can then be moved back to the original isolated network domain to deploy previously obtained licenses to network devices. Please see the Deploying Cisco License Manager in Isolated Networks white paper located at http://www.cisco.com/go/clm for more details.

Rapid license deployment

Simple rule-based policy language completely automates software activation and license management. You can create a simple rule-based policy using common device attributes such as device model, device group, and IP address range and assign a PAK to this policy. This policy can be executed on an on-demand basis, and Cisco License Manager will automatically obtain and deploy the appropriate licenses to the managed devices, matching against the rules in the policy. This helps enable you to focus more on rolling out advanced services in your network using the licensed features.

Transfer licenses from one device to another

You can rehost your licenses by selecting the source and destination devices. Cisco License Manager simplifies this procedure by securely obtaining rehost permission from Cisco.com, revoking the license from the source device, and obtaining and installing the transferred license to the destination device as well as installing a temporary license for the feature being transferred to give you enough time to migrate all connections or traffic to the destination device.

RMA license transfer functionality

Cisco License Manager supports return materials authorization (RMA) license transfer functionality and allows users to transfer licenses from a failed device that is being returned through the RMA process to a new device.

Agentless device management

You can use Cisco License Manager to manage licenses on Cisco devices using a command-line interface (CLI) with Secure Shell (SSH) Protocol/Telnet without needing to configure or enable any agent. In addition, Cisco License Manager can communicate with the license agent in Cisco IOS Software using Extensible Markup Language (XML) over HTTPS.

Detailed reporting

Helps you know exactly which licensed software features you have purchased, how many licenses you have obtained, and which licenses are not yet deployed as well as identify licensable features on devices and check to see whether those features are activated by license. It also aids in audit compliance through its licensing reports indicating proof of purchase. It saves costs by generating redeployable license reports listing licenses that are deployed on devices but are not needed there. The Return Merchandise Authorization Discrepancy report helps you identify inadvertent license discrepancies that can fail audits. Also, Cisco License Manager provides improved reporting with device capabilities and filtering based on various attributes.

Software asset management

Cisco License Manager has improved software asset management and can help you report when your managed assets are end of sale or end of life or if there is a PSIRT advisory active against them.

Java SDK

Allows you to integrate your license and asset management software with Cisco License Manager and help protect existing investments. Java SDK is available for purchase.

Faster failure recovery and troubleshooting

Helps enable you to redeploy licenses from the Cisco License Manager database in case a license is accidentally removed or is corrupted. It also provides the capability to resend licenses from the Cisco.com license server for the device with failed storage and redeploy them. This results in less network downtime. Cisco License Manager also provides the capability to back up and restore its database and configuration files. In addition, Cisco License Manager provides detailed troubleshooting and diagnostic capabilities to identify the root cause of connectivity failure to devices and the Cisco.com license server. Cisco License Manager presents alerts from devices with ITU X.733-based severities.

Broad OS support

Cisco License Manager supports the following operating systems:

(English version only)

Improved scalability

A single installation of Cisco License Manager 3.0 will support up to 500,000 devices and provides improved performance and search capabilities.

Feature

Description and Benefit

Cisco License Manager 3.0 client and server software

Available only by download from http://www.cisco.com/pcgi-bin/tablebuild.pl/clm10

Cisco License Manager 3.0 Java Software Development Kit. One SDK is needed for each development workstation.

CLM3.0-JAVA-SDK

Cisco License Manager 3.0 Java Software Development Kit major upgrade from Cisco License Manager 2.2 Java SDK. One SDK is needed for each development workstation.

CLM3.0-JAVA-SDK-U
