Release Notes for the Cisco 3825 Series Integrated Services Router in an IP RAN Environment for Cisco IOS Release 12.4(19)MR
September 24, 2008
OL-14971-04
Cisco IOS Release 12.4(19)MR
These release notes are for the Cisco 3825 Series Integrated Services Router in an IP Radio Access Network (RAN) Environment for Cisco IOS Release 12.4(19)MR. Cisco IOS Release 12.4(19)MR is required to deploy the Cisco 3825 router in an IP RAN Optimization solution. These release notes are updated to describe new features, memory requirements, hardware support, software platform deferrals, and changes to the microcode and related documents.
For a list of the software caveats that apply to Cisco IOS Release 12.4(19)MR, see the "Caveats in Cisco IOS Release 12.4(19)MR" section.
To review Cisco 3825 Series Integrated Services Router release notes, including Release Notes for the Cisco 3825 Series Integrated Services Router in an IP Radio Access Network Environment for Cisco IOS Release 12.4(19)MR, go to the following URL:
http://www.cisco.com/en/US/products/ps5855/prod_release_notes_list.html
To review release notes for the Cisco IOS Software Releases 12.4 Mainline, including Release Notes for the Cisco 3825 Series Integrated Services Router in an IP Radio Access Network Environment for Cisco IOS Release 12.4(19)MR, go to the following URL:
http://www.cisco.com/en/US/products/ps6350/prod_release_notes_list.html
Contents
This document contains the following sections:
Introduction
With Cisco IOS Release 12.4(16)MR and later, Cisco 3825 series integrated services routers can be used in an Internet Protocol Radio Access Network (IP RAN) environment. The Cisco IP RAN feature provides both:
•
Global System for Mobile Communication (GSM) Abis Optimization over IP and
•
The Cisco IP RAN feature enables bandwidth efficient transport of GSM and UMTS traffic between the Base Transceiver Station (BTS) and the Base Station Controller (BSC) in GSM RANs and between Node B and Radio Network Controllers (RNC) in UMTS RANs. This results in significant reductions in operating expenditures to the mobile wireless operator and enables new revenue-generating services for the future.
System Requirements
When being implemented in an IP RAN solution, the Cisco 3825 series integrated services router requires the following minimum software installation:
•
Memory Requirements
Table 1 lists the required memory for using this software.
Hardware Supported
The following cards are supported on the Cisco 3825 router:
•
•
•
Determining the Software Version
To determine the image and version of Cisco IOS software running on your Cisco 3825 series integrated services router, log in to the Cisco 3825 series integrated services router and enter the show version EXEC command:
router> show versionCisco Internetwork Operating System SoftwareIOS (tm) 3800 Software (C3825-IPRANk9-MZ), Version 12.4(19)MR, EARLY DEPLOYMENT RELEASE SOFTWARE (fcl)Upgrading to a New Software Release
For general information about upgrading to a new software release, refer to Support Download Software at the following URL:
http://www.cisco.com/public/sw-center/index.shtml
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 3825 series integrated services router.
•
•
•
•
New Features in Cisco IOS Release 12.4(19)MR Software
No new features are supported by the Cisco 3825 router for Cisco IOS Release 12.4(19)MR.
New Features in Cisco IOS Release 12.4(16)MR2 Software
In Cisco IOS Release 12.4(16)MR2, the Cisco 3825 router supports the following:
•
New Features in Cisco IOS Release 12.4(16)MR1 Software
In Cisco IOS Release 12.4(16)MR1, the Cisco 3825 router now supports the following:
•
•
•
•
•
•
•
New Features in Cisco IOS Release 12.4(16)MR Software
In Cisco IOS Release 12.4(16)MR, the Cisco 3825 router now supports the following:
•
•
Caveats
This section documents the open and resolved caveats for the Cisco 3825 series integrated services router running Cisco IOS Release 12.4(16)MR through Cisco IOS Release 12.4(19)MR. Only severity 1 through 3 caveats are included.
Caveats describe unexpected behavior in Cisco IOS software releases. Severity 1 caveats are the most serious caveats, severity 2 caveats are less serious, and severity 3 caveats are the least serious of these three severity levels.
Caveats in Cisco IOS Software Releases 12.4 Mainline and Cisco IOS Software Releases 12.4T are also in Cisco IOS Release 12.4(16)MR through Cisco IOS Release 12.4(19)MR.
For information on caveats in Cisco IOS Software Releases 12.4 Mainline, go to the following URL on Cisco.com:
http://www.cisco.com/en/US/products/ps6350/prod_release_notes_list.html
For information on caveats in Cisco IOS Software Releases 12.4T, go to the following URL on Cisco.com:
http://www.cisco.com/en/US/products/ps6441/prod_release_notes_list.html
These documents list severity 1 and 2 caveats and can be found on the Documentation DVD as well as Cisco.com.
Note
The following sections list the open and resolved caveats in the following releases:
•
•
•
•
Caveats in Cisco IOS Release 12.4(19)MR
The following caveats are opened and resolved in Cisco IOS Release 12.4(19)MR.
Open Caveats
This section lists the caveats that are open in Cisco IOS Release 12.4(19)MR.
CSCsr24585
Description: The MPLS packets are not getting classified as per the configured QoS policy.
Workaround: There is no workaround for the Release 12.4(19)MR image.
Resolved Caveats
This section lists the caveats that are resolved in Cisco IOS Release 12.4(19)MR.
CSCso76994
Description: The LNM feature is not fully functional.
1.
2.
Workaround: Software fixes have resulted in the following resolutions:
1.
2.
CSCsq13348
The Cisco IOS Intrusion Prevention System (IPS) feature contains a vulnerability in the processing of certain IPS signatures that use the SERVICE.DNS engine. This vulnerability may cause a router to crash or hang, resulting in a denial of service condition.
Cisco has released free software updates that address this vulnerability. There is a workaround for this vulnerability.
NOTE: This vulnerability is not related in any way to CVE-2008-1447 - Cache poisoning attacks. Cisco Systems has published a Cisco Security Advisory for that vulnerability, which can be found at http://www.cisco.com/en/US/products/products_security_advisory09186a00809c2168.shtml.
This advisory is posted at http://www.cisco.com/warp/public/707/cisco-sa-20080924-iosips.shtml.
CSCsq93138
Description: The user cannot specify the default IMA Group ID on an IMA interface. This is done solely by the system.
Workaround: By using the ima-group id command, the user can configure the IMA Group ID on an IMA interface. If the user configures an IMA Group ID with the system-selected default ID for an existing IMA interface, the system toggles the IMA interface to make the user-configured IMA Group ID the effective IMA Group ID. At the same time, the system toggles the original IMA interface to select a different default IMA Group ID.
Caveats in Cisco IOS Release 12.4(16)MR2
The following caveats are opened and resolved in Cisco IOS Release 12.4(16)MR2.
Open Caveats
This section lists the caveats that are open in Cisco IOS Release 12.4(16)MR2.
CSCsk42419 and CSCsk60020
The Secure Shell server (SSH) implementation in Cisco IOS contains multiple vulnerabilities that allow unauthenticated users the ability to generate a spurious memory access error or, in certain cases, reload the device.
The IOS SSH server is an optional service that is disabled by default, but its use is highly recommended as a security best practice for management of Cisco IOS devices. SSH can be configured as part of the AutoSecure feature in the initial configuration of IOS devices, AutoSecure run after initial configuration, or manually. Devices that are not configured to accept SSH connections are not affected by these vulnerabilities.
Common Vulnerabilities and Exposures (CVE) identifier CVE-2008-1159 has been assigned to this bug.
The Security Advisory for this issue is posted at
http://www.cisco.com/warp/public/707/cisco-sa-20080521-ssh.shtml
CSCsl27667:
Description: MWR uses only the first 16 bits of the assigned control connection ID AVP.
Workaround: There is no workaround for the 12.4(16)MR1 image.
Resolved Caveats
There are no known resolved caveats in Cisco IOS Release 12.4(16)MR2.
Caveats in Cisco IOS Release 12.4(16)MR1
The following caveats are opened and resolved in Cisco IOS Release 12.4(16)MR1.
Open Caveats
This section lists the caveats that are open in Cisco IOS Release 12.4(16)MR1.
CSCsl27667:
Description: MWR uses only the first 16 bits of the assigned control connection ID AVP.
Workaround: There is no workaround for the 12.4(16)MR1 image.
Resolved Caveats
This section lists the caveats that are resolved in Cisco IOS Release 12.4(16)MR1.
CSCsk53991:
Description: ISR ATM cell switching feature is broken.
Workaround: There is no workaround for the 12.4(16)MR image and prior images.
Caveats in Cisco IOS Release 12.4(16)MR
The following caveats are opened and resolved in Cisco IOS Release 12.4(16)MR.
Open Caveats
There are no known open caveats in Cisco IOS Release 12.4(16)MR.
Resolved Caveats
There are no known resolved caveats in Cisco IOS Release 12.4(16)MR.
Troubleshooting
Collecting Data for Router Issues
To collect data for reporting router issues, use the following command:
•
Collecting Data for ROMmon Issues
To collect data for ROMmon issues, use the following command while in EXEC mode:
•
Related Documentation
Related documents for implementing the Cisco 3825 series integrated services router in a RAN-O solution are available on Cisco.com and the Documentation DVD.
Use the following URL to access the related documentation on Cisco.com:
http://www.cisco.com/en/US/products/ps5855/tsd_products_support_series_home.html
Documents related to the Cisco 3825 series integrated services router include the following guides:
•
–
•
–
–
•
–
–
–
•
–
