Cisco Content Security and Control (CSC) SSM Release Notes Version 6.2.1599.5
December 2008
Contents
This document contains release information for the Cisco Content Security and Control (CSC) SSM Version 6.2.1599.5 maintenance release. It includes the following sections:
•
About the CSC SSM Version 6.2.1599.5 Release
•Installing the CSC SSM Version 6.2.1599.5 Release
•Verifying the Installed Version of the CSC SSM Software
•Caveats
•Related Documentation
•Obtaining Documentation and Submitting a Service Request
About the CSC SSM Version 6.2.1599.5 Release
The CSC SSM Version 6.2.1599.5 maintenance release applies only to CSC-SSM-10 and CSC-SSM-20 Versions 6.21599.0 through 6.2.1599.4.
See the "Resolved Caveats" section for information about the caveats that have been resolved by this release.
Installing the CSC SSM Version 6.2.1599.5 Release
You can install this release if you are running CSC SSM Version 6.2.1599.0 through 6.2.1599.4. To verify the version of the CSC SSM software installed on the device, see the "Verifying the Installed Version of the CSC SSM Software" section.
To upgrade the CSC SSM, perform the following steps:
Step 1 You must log into Cisco.com to download the software, which is available at the following URL:
http://www.cisco.com/cisco/software/navigator.html
Note If you do not have a Cisco.com account, to become a registered user, visit the following website:
http://tools.cisco.com/RPF/register/register.do
Step 2 Download the csc6.2.1599.5 .pkg upgrade file from the Software Center on Cisco.com.
Step 3 Access the Trend Micro CSC SSM console by doing the following:
a. Launch ASDM.
b. Choose Configuration > Trend Micro Content Security.
c. Click any link on the Trend Micro configuration pane to open the Trend Micro InterScan for Cisco CSC SSM interface.
Step 4 Choose Administrator > Product Upgrade from the menu.
Step 5 Click Browse and select the .pkg file you downloaded.
Step 6 Click Upload.
Step 7 Click Summary to confirm the installed software version.
Step 8 (Optional) Download the Eicar "Anti-Malware Testfile" from http://www.eicar.org to confirm that the upgrade was successful and that the scanning services have been configured correctly. Check the upper right corner of the Home page.
For more information, see Appendix A, "Reimaging and Configuring the CSC SSM Using the CLI," in the Cisco Content Security and Control (CSC) SSM Administrator Guide.
Verifying the Installed Version of the CSC SSM Software
The software version appears in the following locations:
•The summary pane of the Trend Micro InterScan for Cisco CSC SSM interface.
•Click the Content Security tab on the ASDM Home pane to open the CSC SSM Information screen.
•Through the ASA 5500 series adaptive security appliance CLI.
To confirm the version of software, and software components and patches that are installed on the CSC SSM using the CLI, perform the following steps:
Step 1 Open ASDM.
Step 2 Choose Tools > Command Line Interface to display the Command Line Interface dialog box.
Step 3 In the command line field, enter the show module 1 details command, and then click Send.
The CSC SSM software version information appears.
Getting details from the Service Module, please wait...
ASA 5500 Series Security Services Module-20
Firmware version: 1.0(10)0
Software version: CSC SSM 6.2.1599.5
MAC Address Range: 000b.fcf8.012c to 000b.fcf8.012c
App. Status Desc: CSC SSM scan services are available
Mgmt IP addr: 10.89.130.241
Peer IP addr: <not enabled>
New Features
This section describes the new features for the CSC SSM Version 6.2.1599.5 maintenance release.
•You can import the configuration from different SSM models. Hardware-dependent configurations, such as serial numbers and the number of HTTP scanner processes, should remain unchanged.
•CSC detection logs are purged based on their event time.
Caveats
This section describes the open and resolved caveats for the CSC SSM Version 6.2.1599.5 maintenance release. To view more information about an open or resolved caveat, use the Bug Toolkit on Cisco.com. If you are a registered Cisco.com user, access the Bug Toolkit on cisco.com at the following website:
http://tools.cisco.com/Support/BugToolKit/
To become a registered Cisco.com user, go to the following website:
http://tools.cisco.com/RPF/register/register.do
For your convenience in locating caveats in the Cisco Bug Toolkit, the caveat titles listed in this section are taken directly from the Bug Toolkit database. These caveat titles are not intended to be read as complete sentences, because the title field length is limited. In the caveat titles, some truncation of wording or punctuation may be necessary to provide the most complete and concise description. The only modifications made to these titles are as follows:
•Commands are in boldface type.
•Product names and acronyms may be standardized.
•Spelling and typographical errors may be corrected.
This section includes the following topics:
•Open Caveats
•Resolved Caveats
Open Caveats
Table 1 lists the open caveats in the CSC SSM Version 6.2.1599.5 maintenance release.
Table 1 Open Caveats
ID Number
|
Caveat Title
|
CSCsd17889
|
Nothing seems to happen when downloading infected file from/to web mail.
|
CSCsd18052
|
E-mail notification from the CSC SSM is not received.
|
CSCse12729
|
The spyware pattern number may appear to be rolled back.
|
CSCse12745
|
NRS feature is not working on the CSC SSM after registration. There may be a one-hour delay for the NRS database to be updated. This only affects new customers for the first hour after the license record has been created.
|
CSCsf98493
|
VPN users using proxy have problem browsing via HTTP.
|
CSCsf98538
|
WhiteIPList on NRS disappears from UI.
|
CSCsh27011
|
HP UX "tcp_lift_anchor, can't wait" error message when using FTP i.
|
CSCsh27102
|
Admin UI SSL vulnerability.
|
CSCsi27604
|
Intermittent e-mail corruption when going through CSC.
|
CSCsi40117
|
100% CPU issue.
|
CSCsi43395
|
Do not send disconnect-syslog when HTTP receives RST.
|
CSCsi65720
|
Secondary DNS server setup is wiped out by session 1 do setup dns command.
|
CSCsj10645
|
CSC still filters large size messages even if disabling POP3 scanning.
|
CSCsj91181
|
FTP service may stop under stress condition.
|
CSCsj91182
|
CSC cannot download pattern/engine from TMCM.
|
CSCsj91183
|
ConnectWise application does not load when scanned by CSC via HTTP.
|
CSCsk07553
|
Phishing websites only categorized without -www-.
|
CSCsk07581
|
Incorrect URL for submitting potential phishing URL to TrendLabs.
|
CSCsk08014
|
CSC locks-up and stays in reload state after upgrading to 6.2.1599.0.
|
CSCsk83986
|
Add additional skip content for new MIME type for www.unitedstreaming.
|
CSCsl11398
|
Add support for FTP APPEND command.
|
CSCsq37785
|
TMCM agent.ini file gets corrupted.
|
CSCsq56401
|
CSC may go unresponsive if the route cache reaches 262k.
|
CSCsr11684
|
RETR command blocked by CSC-SSM in FTP passive mode.
|
CSCsr75667
|
CSC-SSM does not handle Office 2007 files correctly.
|
CSCsr75669
|
CSC-SSM file blocking does not block Office 2007 files.
|
CSCsr95448
|
GUI timeout inconsistent.
|
CSCsu42556
|
Module in slot 1 experienced a data channel communication failure.
|
CSCsu68672
|
Feature request to support non-IP address for ERS-approved IP address.
|
CSCsv19800
|
HTTP access to results from images.google.com is blocked by URL filter.
|
CSCsv43913
|
POP3 anti-spam when spam mail is configured to be deleted.
|
CSCsv75448
|
CSC trims FQDN in URL requests.
|
CSCsv77805
|
No e-mail notification is sent for scheduled updates.
|
CSCsw27401
|
CSC memory used in ASDM is not reported correctly.
|
Resolved Caveats
Table 2 lists the resolved caveats in the CSC SSM Version 6.2.1599.5 maintenance release.
Table 2 Resolved Caveats
ID Number
|
Caveat Title
|
CSCsk83985
|
Scan server may have a memory leak.
|
CSCsr66676
|
HTTP limits file downloads at 2GB.
|
CSCsr75670
|
Improve syslog messages to indicate where the syslog originated from, either the HTTP scanner or URL rating server.
|
CSCsu06743
|
HTTP file blocking notification GUI does not accept new line.
|
CSCsu39231
|
CSC blocks its own URL rating request when .txt files are configured to be blocked in HTTP and when ASA is not configured to skip CSC management traffic.
|
CSCsu55632
|
HTTP scanner seems to crash and cause "Page cannot be displayed" errors in browser.
|
CSCsv75448
|
CSC rewrites HTTP URI in proxy requests.
|
Related Documentation
For additional information, see the ASDM online Help or the following documentation on Cisco.com:
•Documentation Roadmap for the Cisco ASA 5500 Series, at: http://www.cisco.com/en/US/products/ps6120/products_documentation_roadmaps_list.html
•Cisco Content Security and Control (CSC) SSM Administrator Guide, at: http://www.cisco.com/en/US/docs/security/csc/csc62/administration/guide/csc62adm.html
•Cisco ASDM Release Notes, at: http://www.cisco.com/en/US/products/ps6120/prod_release_notes_list.html
•Cisco ASA 5500 Series Hardware Maintenance Guide, at: http://www.cisco.com/en/US/products/ps6120/prod_installation_guides_list.html
•Cisco ASA 5500 Series Adaptive Security Appliance Getting Started Guide, at: http://www.cisco.com/en/US/products/ps6120/prod_installation_guides_list.html
•Cisco ASA 5500 Series Release Notes, at: http://www.cisco.com/en/US/products/ps6120/prod_release_notes_list.html
•Cisco ASA 5500 Series Configuration Guide Using the CLI, at: http://www.cisco.com/en/US/products/ps6120/products_installation_and_configuration_guides_list.html
•Cisco Security Appliance Command Reference, at: http://www.cisco.com/en/US/products/ps6120/prod_command_reference_list.html
•Cisco Security Appliance System Log Messages, at: http://www.cisco.com/en/US/products/ps6120/products_system_message_guides_list.html
•Open Source Software Licenses for ASA and PIX Security Appliances, at: http://www.cisco.com/en/US/products/ps6120/products_licensing_information_listing.html
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What's New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What's New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS version 2.0.
For additional ASA 5500 Series Adaptive Security Appliance documentation, see the following URL and log in with your Cisco.com username and password:
http://www.cisco.com/en/US/partner/products/ps6120/tsd_products_support_series_home.html
