Cisco Content Security and Control (CSC) SSM Release Notes Version 6.2.1599.3
June 2008
Contents
This document contains release information for the Cisco Content Security and Control (CSC) SSM Version 6.2.1599.3 maintenance release. It includes the following sections:
•
About the CSC SSM Version 6.2.1599.3 Release
•Installing the CSC SSM Version 6.2.1599.3 Release
•Verifying the Installed Version of the CSC SSM Software
•Caveats
•Related Documentation
•Obtaining Documentation and Submitting a Service Request
About the CSC SSM Version 6.2.1599.3 Release
The CSC SSM Version 6.2.1599.2 maintenance release applies only to CSC-SSM-10 and CSC-SSM-20 Versions 6.21599.0, 6.2.1599.1, and 6.2.1599.2.
See the "Resolved Caveats" section for information about the caveats that have been resolved by this release.
Installing the CSC SSM Version 6.2.1599.3 Release
You can install this release if you are running CSC SSM Version 6.2.1599.0, 6.2.1599.1, or 6.2.1599.2. To verify the version of the CSC SSM software installed on the device, see the "Verifying the Installed Version of the CSC SSM Software" section.
To upgrade the CSC SSM, perform the following steps:
Step 1 Download the csc6.2.1599.3 .pkg upgrade file from the Software Center on Cisco.com. You need to log into Cisco.com to download the software. If you do not have a Cisco.com account, visit the following website to become a registered user:
http://tools.cisco.com/RPF/register/register.do
Step 2 Access the Trend Micro CSC SSM console by doing the following:
a. Launch ASDM.
b. Choose Configuration > Trend Micro Content Security.
c. Click any link on the Trend Micro configuration page to open the Trend Micro InterScan for Cisco CSC SSM interface.
Step 3 Choose Administrator > Product Upgrade from the menu.
Step 4 Click Browse and select the .pkg file you downloaded.
Step 5 Click Upload.
Step 6 Click Summary to confirm the installed software version.
Step 7 (Optional) Use an Eicar test file to confirm that the upgrade was successful and that the scanning services have been configured correctly. Download the "Anti-Malware Testfile" from http://www.eicar.org.
For more information, see Appendix A, "Reimaging and Configuring the CSC SSM Using the CLI," in the Cisco Content Security and Control SSM Administrator Guide.
Verifying the Installed Version of the CSC SSM Software
The software version appears in the following locations:
•The summary page of the Trend Micro InterScan for Cisco CSC SSM interface.
•Click the Content Security tab on the ASDM Home page to open the CSC SSM Information screen.
•Through the ASA 5500 series adaptive security appliance CLI.
To confirm the version of software, and software components and patches that are installed on the CSC SSM using the CLI, perform the following steps:
Step 1 Open ASDM.
Step 2 Choose Tools > Command Line Interface to display the Command Line Interface dialog box.
Step 3 In the command line field, enter the show module 1 details command, and then click Send.
The CSC SSM software version information appears.
Getting details from the Service Module, please wait...
ASA 5500 Series Security Services Module-20
Firmware version: 1.0(10)0
Software version: CSC SSM 6.2.1599.3
MAC Address Range: 000b.fcf8.012c to 000b.fcf8.012c
App. Status Desc: CSC SSM scan services are available
Mgmt IP addr: 10.89.130.241
Peer IP addr: <not enabled>
New Features
This section describes the new features for the CSC SSM Version 6.2.1599.3 maintenance release.
•To aid in troubleshooting, CSC log collection records engineering builds that have been installed as part of the revision history.
•You may configure the free memory monitoring threshold. The default value is 20 MB.
Caveats
This section describes the open and resolved caveats for the CSC SSM Version 6.2.1599.3 maintenance release. To view more information about an open or resolved caveat, use the Bug Toolkit on Cisco.com. If you are a registered Cisco.com user, access the Bug Toolkit on cisco.com at the following website:
http://tools.cisco.com/Support/BugToolKit/
To become a registered Cisco.com user, go to the following website:
http://tools.cisco.com/RPF/register/register.do
For your convenience in locating caveats in the Cisco Bug Toolkit, the caveat titles listed in this section are taken directly from the Bug Toolkit database. These caveat titles are not intended to be read as complete sentences, because the title field length is limited. In the caveat titles, some truncation of wording or punctuation may be necessary to provide the most complete and concise description. The only modifications made to these titles are as follows:
•Commands are in boldface type.
•Product names and acronyms may be standardized.
•Spelling and typographical errors may be corrected.
This section includes the following topics:
•Open Caveats
•Resolved Caveats
Open Caveats
Table 1 lists the open caveats in the CSC SSM Version 6.2.1599.3 maintenance release.
Table 1 Open Caveats
ID Number
|
Caveat Title
|
CSCsd17889
|
Nothing seems to happen when downloading infected file from/to webmail.
|
CSCsd17954
|
The HTTP proxy connection cannot tunnel through the CSC SSM.
|
CSCsd18011
|
FTP file blocking will not work when file unscanned due to cfg.
|
CSCsd18052
|
E-mail notification from the CSC SSM is not received.
|
CSCse12729
|
The spyware pattern number may appear to be rolled back.
|
CSCse12745
|
NRS feature is not working on the CSC SSM after registration.
|
CSCse12755
|
Some spyware may be detected even if Spyware category is not enabled.
|
CSCsf05298
|
Citrix not supported with CSC module.
|
CSCsf98493
|
VPN users using proxy have problem browsing via HTTP.
|
CSCsf98538
|
White IP List on NRS will disappear from UI.
|
CSCsh27011
|
HP UX tcp_lift_anchor, can't wait error message when doing FTP i.
|
CSCsh27102
|
Admin UI SSL vulnerability.
|
CSCsh70101
|
No error message for invalid URL blocking import file.
|
CSCsi27604
|
Intermittent e-mail corruption when going through CSC.
|
CSCsi40117
|
100% CPU issue.
|
CSCsi43395
|
Do not send disconnect-syslog when HTTP receives RST.
|
CSCsi65720
|
Secondary DNS server setup is wiped out by session 1 do setup dns command.
|
CSCsj10645
|
CSC still filters large size messages even if disabling POP3 scanning.
|
CSCsj91181
|
FTP service may stop under stress condition.
|
CSCsj91182
|
CSC cannot download pattern/engine from TMCM.
|
CSCsj91183
|
ConnectWise application does not load when scanned by CSC via HTTP.
|
CSCsj91185
|
Webmail scanning displays incorrect color when adding new entries.
|
CSCsk07553
|
CSC: Phishing websites only categorized without www.
|
CSCsk07581
|
CSC: Incorrect URL for submit potential phishing URL to TrendLabs.
|
CSCsk08014
|
CSC locks up and stays in Reload state after upgrading to 6.2.1599.0.
|
CSCsk09801
|
CSC-SSM Enhancement: block SMTP e-mail with blank subject field.
|
CSCsk39837
|
CSC-SSM upgrade from 6.1.1519 to 6.2.1599 via .pkg might fail.
|
CSCsk83984
|
CSC: free memory is not correctly calculated/reported.
|
CSCsk83986
|
Add additional skip content for new MIME type for www.unitedstreaming.com.
|
CSCsk90093
|
Enhance online help for unscanned corrupted files.
|
CSCsl11398
|
Add support for FTP APPEND command.
|
CSCsl33414
|
CSC: Importing e-mail addresses under white list may fail.
|
CSCsl44473
|
CSC: Logging facility settings do not change from local3.
|
CSCsl54663
|
CSC: Slow e-mail delivery from certain domains.
|
CSCsl54989
|
CSC module does not delete POP3 spam.
|
CSCso02432
|
CSC Blocked Senders Import does not allow dots in user names.
|
CSCso67276
|
CSC: Failover may not work with cisco123 encryption key.
|
CSCso73795
|
CSC: Module does not take the activation keys provided.
|
CSCso99926
|
CM agent restarting.
|
CSCsq00778
|
CSC 6.2: accessing windows update; slow access through CSC to services.
|
Resolved Caveats
Table 2 lists the resolved caveats in the CSC SSM Version 6.2.1599.3 maintenance release.
Table 2 Resolved Caveats
ID Number
|
Caveat Title
|
CSCsm91133
|
FTP scanner sometimes does not forward 226 Transfer Complete to the client and causes the FTP session to time out.
|
CSCsq03282
|
CSC is misclassifying Microsoft sites.
|
CSCsq37771
|
SMTP scanner returns a 5xx code when DATA command returns a non-3xx code.
|
CSCsq37778
|
TMCM Agent.ini may be corrupt and cause TMCM services to stop/restart.
|
Related Documentation
For additional information, see the ASDM online Help or the following documentation found on Cisco.com:
•Cisco Content Security and Control SSM Administrator Guide
•Cisco ASDM Release Notes
•Cisco ASA 5500 Series Hardware Maintenance Guide
•Cisco ASA 5500 Series Adaptive Security Appliance Getting Started Guide
•Cisco ASA 5500 Series Release Notes
•Cisco Security Appliance Command Line Configuration Guide
•Cisco Security Appliance Command Reference
•Cisco Security Appliance System Log Messages Guide
•Open Source Software Licenses for ASA and PIX Security Appliances
