Cisco Security Modules for Security Appliances

Table Of Contents

Cisco Content Security and Control Version 6.1.1569.0 Patch Release Notes

Contents

About the CSC 6.1.1569.0 Patch

Installing the CSC SSM 6.1.1569.0 Patch

Verifying the Installed Version of the CSC SSM Software

Caveats

Open Caveats

Resolved Caveats

Related Documentation

Obtaining Documentation and Submitting a Service Request

Cisco Content Security and Control Version 6.1.1569.0 Patch Release Notes

---

November 2006

Contents

This document contains release information for the Cisco Content Security and Control (CSC) Version 6.1.1569.0 patch release. It includes the following sections:

•About the CSC 6.1.1569.0 Patch

•Installing the CSC SSM 6.1.1569.0 Patch

•Verifying the Installed Version of the CSC SSM Software

•Caveats

•Related Documentation

•Obtaining Documentation and Submitting a Service Request

About the CSC 6.1.1569.0 Patch

The CSC Version 6.1.1569.0 patch contains the following new features:

•Password reset, which allows you to reset the default CSC SSM password to "cisco."

•A single password is required to access the CSC SSM GUI and CLI. For more information, see the Cisco Content Security and Control SSM Administrator Guide.

•Version numbering has been changed to reflect the software version number, build number, and patch release number. The format is as follows:

major software version.minor software version.build number.patch release number

•License renewal is available through the Cisco website.

•The TCP window size has been adjusted.

•The URL Reclassification Request has been changed to a web-based submission.

•Workaround to CSCsd17818: Use the adaptive security appliance Modular Policy Framework to bypass CSC SSM scanning of website IP addresses.

See the "Resolved Caveats" section for information about the caveats that have been resolved by this patch.

Installing the CSC SSM 6.1.1569.0 Patch

Install this patch only if you are running CSC SSM version 6.1-b1519 and version 6.1, patch 1. To verify the version of the CSC SSM installed on the device, see the "Verifying the Installed Version of the CSC SSM Software" section.

To upgrade the CSC SSM, perform the following steps:

---

Step 1 Download the csc-p-6.1.1569.0.pkg file from the Software Center on Cisco.com. You need to log into Cisco.com to download the software. If you do not have a Cisco.com account, visit the following website to become a registered user:

http://tools.cisco.com/RPF/register/register.do

Step 2 Access the Trend Micro CSC SSM console by doing the following:

a. Launch ASDM.

b. Choose Configuration > Trend Micro Content Security.

Step 3 Choose Administrator > Product Upgrade from the menu.

Step 4 Click Browse and select the .pkg file you downloaded.

Step 5 Click Install.

Step 6 Click Summary to confirm the installed software version.

Step 7 Optional) Use an Eicar test file to confirm that the upgrade was successful and that the scanning services have been configured correctly.

---

For more information, see Appendix A, "Reimaging and Configuring the CSC SSM Using the CLI," in the Cisco Content Security and Control SSM Administrator Guide.

Verifying the Installed Version of the CSC SSM Software

You can confirm the version of the CSC SSM software, and software components and patches from the ASA 5500 series adaptive security appliance CLI.

---

Note The software version also appears on the main page of the Trend Micro InterScan for Cisco CSC SSM interface.

---

To view the version of software installed on the CSC SSM using the CLI, perform the following steps:

---

Step 1 Use the session command to access the CSC SSM. Use cisco as the login name.

hostname(config)# session 1

Opening command session with slot 1.

Connected to slot 1. Escape character sequence is 'CTRL-^X'.

login: cisco

Password:

     Trend Micro InterScan for Cisco CSC SSM Setup Main Menu

---------------------------------------------------------------------

1. Network Settings

2. Date/Time Settings

3. Product Information

4. Service Status

5. Change Password for Command Line Interface

6. Restore Factory Default Settings

7. Troubleshooting Tools

8. Reset Management Port Access Control List

9. Ping

10. Exit ...

Step 2 Type 3 and press Enter to access the Product Information screen.

The Product Information screen displays the version and build number of each component of the CSC SSM. Installed patches appear below the component list.

Enter a number from [1-10]: 3

                       Product Information

---------------------------------------------------------------------

Main           version 6.1 build 1519

Mail component version 5.5 build 1118

Web component  version 2.1 build 1154

Patches:

p-6.1-b1519-1 07/10/2006 22:31:14 CSC SSM 6.1 Patch 1

Press Enter to continue ...

Step 3 Press Enter.

The Trend Micro InterScan for Cisco CSC SSM Setup Main Menu appears.

---

Caveats

This section describes the open and resolved caveats for the CSC SSM 6.1.1569.0 release. To view more information about an open or resolved caveat, use the Bug Toolkit on Cisco.com. If you are a registered Cisco.com user, access the Bug Toolkit on cisco.com at the following website:

http://tools.cisco.com/Support/BugToolKit/

To become a registered Cisco.com user, go to the following website:

http://tools.cisco.com/RPF/register/register.do

For your convenience in locating caveats in the Cisco Bug Toolkit, the caveat titles listed in this section are taken directly from the Bug Toolkit database. These caveat titles are not intended to be read as complete sentences, because the title field length is limited. In the caveat titles, some truncation of wording or punctuation may be necessary to provide the most complete and concise description. The only modifications made to these titles are as follows:

•Commands are in boldface type.

•Product names and acronyms may be standardized.

•Spelling and typographical errors may be corrected.

This section includes the following topics:

•Open Caveats

•Resolved Caveats

Open Caveats

Table 1 lists the caveats that are open in Version CSC 6.1.1569.0.

Table 1 Open Caveats

ID Number	Caveat Title
CSCsd05974	TCP flow dropped due to CSC card failed during SSM stress.
CSCsd17818	Yahoo! Finance MarketTracker does not work. For a workaround, see About the CSC 6.1.1569.0 Patch.
CSCsd17889	Nothing seems to happen when downloading infected file from/to webmail.
CSCsd17954	The HTTP proxy connection cannot tunnel through the CSC SSM.
CSCsd18011	FTP file blocking will not work when file unscanned due to cfg.
CSCsd18030	Connections may be interrupted during SSM service failure.
CSCsd18044	Connections may be interrupted during the SSM restarting period.
CSCsd18052	E-mail notification from the CSC SSM is not received.
CSCsd18060	With CSC enabled, large file transfer using HTTP/FTP or Windows Update fail.
CSCsd59143	Modify e-mails sent by Trend CSC-SSM module to include device name, IP.
CSCse12729	The spyware pattern number may appear to be rolled back.
CSCse12745	NRS feature is not working on the CSC SSM after registration.
CSCse12755	Some spyware may be detected even if Spyware category is not enabled.
CSCse12767	Fails to convert non-UTF8 Japanese characters to UTF-8.
CSCse12772	Filename may not be properly displayed in the e-mail inline insertion.
CSCse12781	Japanese strings may not be displayed correctly in system log messages.
CSCse12784	Multi-byte strings are not allowed on the GUI.
CSCse12786	Original e-mail may break if not encoded in UTF-8.
CSCse12791	Multi-byte filename may not be displayed correctly.
CSCse89728	Number of licensed seats shows a different value for Base and Plus licenses.
CSCsf05298	Citrix not supported with CSC module.
CSCsf12514	CSC module needs to support TFTP blocksize option - RFC 2347, RFC 2348.
CSCsf26197	CSC software blocks Ameritrade streamer.
CSCsf27606	CSC software stops processing POP3 traffic.
CSCsf28591	CSC module generates compact Flash almost-full messages.
CSCsf98493	VPN users using proxy have problem browsing via HTTP: 1264.
CSCsf98538	White IP List on NRS will disappear from Trend UI: 1253.
CSCsg25501	Bypass filter for CSC module.
CSCsg28389	HTTP scanner causes system to hit 100% busy.
CSCsg52819	CSC module - Import function for user-defined domain lists
CSCsg72210	Trend URL filtering service does not currently support SOCKS-based proxy service.
CSCsg76794	Last 30-day counter is not updating correctly.
CSCsg82181	Flash image on www.cisco.com home page sometimes cannot be loaded.

Resolved Caveats

Table 2 lists the caveats that have been resolved in Version CSC 6.1.1569.0.

Table 2 Closed Caveats

ID Number	Caveat Title
CSCse38627	Last security event is overwritten by a POP3 or SMTP event.
CSCse67660	Active Update failure messages may confuse customers.
CSCse71477	CSC CPU and node counters are not displayed correctly in Japanese OS.
CSCse78267	Network Settings displayed on a running CLI Menu may not be updated right after importing configuration on CSC GUI, even if the new settings have been applied and are effective.
CSCse78267	Gather Log feature on CLI Menu sometimes returns an error.
CSCse78267 CSCsf98485	URL Filtering service does not support HTTP proxy.
CSCsf08627	CSC/IPS Password Reset support has been added in ASDM 5.2.2.
CSCsf19517	CSC Password screen Apply button is not enabled.
CSCsf98459	CSC CLI Menu and CSC GUI enforce different password lengths.
CSCsf98496	URL Exception List does not allow more than 50 characters.
CSCsf98499	"SMTP Incoming Domain" can be emptied.
CSCsf98506	Windows Update sometimes fails on corrupted ZIP detected.
CSCsf98519	HTTP URL Filtering has a long timeout.
CSCsf98551	Change Trend service alias for receiving customer's submission of URL reclassification.
CSCsf98558	"Check Status Online" on CSC GUI License window always updates "Last Status Check."
CSCsg19161	CSC 6.1 is not detecting incorrect password entry.
CSCsg26887	Incorrect TMCM config causes active update failure.
CSCsg28389	CSC module 100-percent-CPU users cannot access network.
CSCsg31261	Power cycle sometimes causes CSC to disable Mail filters.
CSCsg32958	Unable to tunnel SMTP-TLS traffic through CSC.
CSCsg71856	Unable to browse some websites, e.g., wisbar.org.
CSCsg72173	Duplicate system log message is generated when multiple spyware applications are found in a compressed file.
CSCsg72185	URL Filtering cache does not expire.
CSCsg73233	CSC GUI displays "Automatic synchronization is currently in progress" when failover configuration is saved.
CSCsg73302	Enter "<>'" as URL Blocking rules on CSC GUI breaks GUI.
CSCsg73427	The "View license detail online" link does not work.
CSCsg79130	FTP EPSV EPRT options not working.
CSCsg82129	CSC jumps to 100% CPU and no new connections can be established.
CSCsg82152	FTP extension EPSV and EPRT did not work through CSC and are now blocked.

Related Documentation

For additional information, see the ASDM online Help or the following documentation found on Cisco.com:

•Cisco Content Security and Control SSM Administrator Guide

•Cisco ASDM Release Notes

•Cisco ASA 5500 Series Hardware Installation Guide

•Cisco ASA 5500 Series Adaptive Security Appliance Getting Started Guide

•Cisco ASA 5500 Series Release Notes

•Cisco Security Appliance Command Line Configuration Guide

•Cisco Security Appliance Command Reference

Obtaining Documentation and Submitting a Service Request

For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What's New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What's New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS version 2.0.
