Cisco ASA 5500 Series Release Notes Version 7.0(4)
Contents
Introduction
System Requirements
Memory Requirements
Determining the Software Version
Upgrading to a New Software Release
New Features
Important Notes
Important Notes in Release 7.0
Common Criteria EAL4+
FIPS 140-2
Hostname and Domain Name Limitation
WebVPN ACLS and DNS Hostname
Proxy Server and ASA
Mismatch PFS
ACS Radius Authorization Server
Readme Document for the Conduits and Outbound List Conversion Tool 1.2
User Upgrade Guide
Features not Supported in Version 7.0
MIB Supported
Downgrade to Previous Version
Caveats
Open Caveats - Release 7.0(4)
Resolved Caveats - Release 7.0(4)
Related Documentation
Software Configuration Tips on the Cisco TAC Home Page
Obtaining Documentation and Submitting a Service Request
Cisco ASA 5500 Series Release Notes Version 7.0(4)
October 2005
Contents
This document includes the following sections:
•
Introduction
•System Requirements
•New Features
•Important Notes
•Caveats
•Related Documentation
•Obtaining Documentation and Submitting a Service Request
Introduction
The Cisco ASA 5500 series security appliance delivers unprecedented levels of defense against threats to the network with deeper web inspection and flow specific analysis, improved secure connectivity through end-point security posture validation and voice and video over VPN support. It also provides enhanced support for intelligent information networks through improved network integration, resiliency, and scalability. This release introduces significant enhancements to all major functional areas, including: firewalling and inspection services, VPN services, network integration, high-availability services, and management/monitoring.
For more information on all the new features, see New Features.
Additionally, the Cisco ASA 5500 series security appliance software supports Adaptive Security Device Manager. ASDM is a browser-based, Java applet used to configure and monitor the software on the security appliances. ASDM is loaded from the security appliance, then used to configure, monitor, and manage the device.
System Requirements
The sections that follow list the system requirements for operating a Cisco ASA 5500 series security appliance. This section includes the following topics:
•Memory Requirements
•Determining the Software Version
•Upgrading to a New Software Release
Memory Requirements
Table 1 lists the DRAM memory requirements for the Cisco ASA 5500 series security appliance.
Table 1 DRAM Memory Requirements
ASA Model
|
DRAM Memory
|
ASA 5510
|
256 MB
|
ASA 5520
|
512 MB
|
ASA 5540
|
1 GB
|
All Cisco ASA 5500 series security appliances require a minimum of 64 MB of internal CompactFlash.
Determining the Software Version
Use the show version command to verify the software version of your Cisco ASA 5500 series security appliance.
Upgrading to a New Software Release
If you have a Cisco.com (CDC) login, you can obtain software from the following website:
http://www.cisco.com/cisco/software/navigator.html
New Features
Released: October 15, 2005
Table 2 lists the new features for ASA and PIX Version 7.0(4)/ASDM Version 5.0(4).
Table 2 New Features for ASA and PIX Version 7.0(4)/ASDM Version 5.0(4)
Feature
|
Description
|
Platform Features
|
Support for the 4GE SSM
|
The 4GE Security Services Module (SSM) is an optional I/O card for the adaptive security appliance. The 4GE SSM expands the total number of ports available on the security appliance, providing four additional ports with Ethernet (RJ-45) or SFP (fiber optic) connections.
|
VPN Features
|
WebVPN Capture Feature
|
The WebVPN capture feature lets you log information about websites that do not display properly over a WebVPN connection. You can enable the WebVPN capture feature with the capture command, but note that it has an adverse affect on the performance of the security appliance. So, be sure to disable this feature after you have captured the information that you need for troubleshooting.
|
Auto Update Over a VPN Tunnel
|
With this release, the auto-update server command has a new source interface argument that lets you specify an interface, such as a VPN tunnel used for management access and specified by the management-access command:
auto-update server url [source interface] [verify-certificate]
|
HTTP proxy applet
|
The HTTP proxy is an Internet Proxy, that supports both HTTP and HTTPS connections. The HTTP proxy code modifies the browser proxy configuration dynamically to redirect all browser HTTP/S requests to the new proxy configuration. This allows the Java Applet to take over as the proxy for the browser.
HTTP Proxy can be used in conjunction with the Port Forwarding (Application Access) feature or by itself.
Note The HTTP proxy feature only works when using Internet Explorer.
On some of the older computers, running Windows XP, the RunOnce Reg-Key is not available, causing the Port Forwarding HTTP-Proxy feature to fail when attempting to modify Proxy settings on Internet Explorer.
You can mannually change the registry. Complete the following steps to change the registry manually:
a. Click Start | Run.
b. Type regedit in the open text box, and click OK.
c. Open this folder: HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\
d. Right click inside the CurrentVersion and select New | Key.
e. Name the new key RunOnce.
f. Click OK.
To configure file access and file browsing, MAPI Proxy, HTTP Proxy, and URL entry over WebVPN for this user or group policy, use the functions command in WebVPN mode.
|
IPSec VPN: Add support for cascading ACLs
|
Cascading ACLs involves the insertion of deny ACEs to bypass evaluation against an ACL and resume evaluation against a subsequent ACL in the crypto map set. Because you can associate each crypto map with different IPSec settings, you can use deny ACEs to exclude special traffic from further evaluation in the corresponding crypto map, and match the special traffic to permit statements in another crypto map to provide or require different security. The sequence number assigned to the crypto ACL determines its position in the evaluation sequence within the crypto map set.
|
Troubleshooting and Monitoring Features
|
Crashinfo Enhancement
|
Output from the crashinfo command might contain sensitive information that is inppropriate for viewing by all users connected to the security appliance. The new crashinfo console disable command lets you suppress the output from displaying on the console.
|
Rate limiting of Syslog messages
|
The logging rate limit enables you to limit the rate at which system log messages are generated. You can limit the number of system messages that are generated during a specified time interval.
You can limit the message generation rate for all messages, a single message ID, a range of message IDs, or all messages with a particular severity level. To limit the rate at which system log messages are generated, use the logging rate-limit command.
|
Firewall Features
|
Connection timeout using Modular Policy Framework
|
The new set connection timeout command lets you configure the timeout period, after which an idle TCP connection is disconnected.
|
Downloadable ACL Enhancements
|
A new feature has been added to ensure that downloadable ACL requests sent to a RADIUS server come from a valid source through the Message-Authenticator attribute.
Upon receipt of a RADIUS authentication request that has a username attribute containing the name of a downloadable ACL, Cisco Secure ACS authenticates the request by checking the Message-Authenticator attribute. The presence of the Message-Authenticator attribute prevents malicious use of a downloadable ACL name to gain unauthorized network access. The Message-Authenticator attribute and its use are defined in RFC 2869, RADIUS Extensions, available at http://www.ietf.org.
|
Converting Wildcards to Network Mask in Downloadable ACL
|
Some Cisco products, such as the VPN 3000 concentrator and Cisco IOS routers, require you to configure dowloadable ACLs with wildcards instead of network masks. The Cisco ASA 5500 adaptive security appliance, on the other hand, requires you to configure downloadable ACLs with network masks. This new feature allows the security appliance to convert a wildcard to a netmask internally. Translation of wildcard netmask expressions means that downloadable ACLs written for Cisco VPN 3000 series concentrators can be used by the security appliance without altering the configuration of the downloadable ACLs on the RADIUS server.
You can configure ACL netmask conversion on a per-server basis, using the acl-netmask-convert command, available in the AAA-server configuration mode.
|
Application Inspection Features
|
Support GTP Load Balancing Across GSNs
|
If the security appliance performs GTP inspection, by default the security appliance drops GTP responses from GSNs that were not specified in the GTP request. This situation occurs when you use load-balancing among a pool of GSNs to provide efficiency and scalability of GPRS. You can enable support for GSN pooling by using the permit response command. This command configures the security appliance to allow responses from any of a designated set of GSNs, regardless of the GSN to which a GTP request was sent.
|
Important Notes
Important Notes in Release 7.0
This section lists important notes related to release 7.0(4).
Common Criteria EAL4+
For information on common criteria EAL4+, see the Installation and Configuration for Common Criteria EAL4+ Evaluated Cisco Adaptive Security Appliance, Version 7.0(4) document.
FIPS 140-2
The Cisco ASA 5500 series security appliance is on the FIPS 140-2 Pre-Validation List.
Hostname and Domain Name Limitation
When using ASDM, the hostname and domain names combined should not be more than 63 characters long. If the hostname and domain names combined is more than 63 characters, you will get an error message.
WebVPN ACLS and DNS Hostname
When a deny webtype URL ACL (DNS-based) is defined, but the DNS-based URL is not reachable, a "DNS Error" popup is displayed on the browser. The ACL hitcounter is also not incremented.
If the URL ACL is defined by an IP instead of DNS name, then the traffic flow hitting the ACL will be recorded in the hitcounter and a "Connection Error" is displayed on the browser.
Proxy Server and ASA
If WebVPN is configured to use an HTTP(S)-proxy server to service all requests for browsing HTTP and/or HTTPS sites, the client/browser may expect the following behavior:
1. If the ASA cannot communicate with the HTTPS or HTTPS proxy server, a "connection error" is displayed on the client browser.
2. If the HTTP(S) proxy cannot resolve or reach the requested URL, it should send an appropriate error to the ASA, which in turn will display it to the client browser.
Only when the HTTP(S) proxy server notifies the ASA of the inaccessible URL, can the ASA notify the error to the client browser.
Mismatch PFS
The PFS setting on the VPN client and the security appliance must match.
ACS Radius Authorization Server
When certificate authentication is used in conjuction with Radius authorization, the ACS server sends a bogus Group=CISCOACS:0003b9c6/5a940131/username and is displayed in the vpn-session database.
Readme Document for the Conduits and Outbound List Conversion Tool 1.2
The Cisco ASA 5500 series security appliance Outbound/Conduit Conversion tool assists in converting configurations with outbound or conduit commands to similar configurations using ACLs. ACL-based configurations provide uniformity and leverage the powerful ACL feature set. ACL based configurations provide the following benefit:
•ACE Insertion capability - System configuration and management is greatly simplified by the ACE insertion capability that allows users to add, delete or modify individual ACEs.
User Upgrade Guide
•For a list of deprecated features, and user upgrade information, go to the following URL:
http://www.cisco.com/en/US/docs/security/asa/asa70/vpn3000_upgrade/upgrade/guide/migr_vpn.html
Features not Supported in Version 7.0
The following features are not supported in Version 7.0(4):
•PPPoE
•L2TP over IPSec
•PPTP
MIB Supported
For information on MIB Support, go to:
http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml
Downgrade to Previous Version
To downgrade to a previous version of the operating system software (software image), use the downgrade command in privileged EXEC mode. For more information and a complete description of the command syntax, see the Cisco Security Appliance Command Reference.
Caveats
The following sections describe the caveats for the 7.0(4) release.
For your convenience in locating caveats in Cisco's Bug Toolkit, the caveat titles listed in this section are drawn directly from the Bug Toolkit database. These caveat titles are not intended to be read as complete sentences because the title field length is limited. In the caveat titles, some truncation of wording or punctuation may be necessary to provide the most complete and concise description. The only modifications made to these titles are as follows:
•Commands are in boldface type.
•Product names and acronyms may be standardized.
•Spelling errors and typos may be corrected.
Note If you are a registered cisco.com user, view Bug Toolkit on cisco.com at the following website:
http://tools.cisco.com/Support/BugToolKit/
To become a registered cisco.com user, go to the following website:
http://tools.cisco.com/RPF/register/register.do
Open Caveats - Release 7.0(4)
Table 3 Open Caveats
ID Number
|
Software Release 7.0(4)
|
Corrected
|
Caveat Title
|
CSCeg57001
|
No
|
Packet does not come to inspect after no inspect and inspect
|
CSCeh15557
|
No
|
Assertion in tmatch_compile_proc, all memory is not freed.
|
CSCeh18115
|
No
|
Authentication not triggered sometimes when URL filtering enabled.
|
CSCeh32087
|
No
|
PIM sends Register with untranslated IP when NAT pool exhausted.
|
CSCeh43554
|
No
|
Device may reload if showing and removing config at the same time
|
CSCeh46345
|
No
|
Dynamic L2L could pass clear text traffic when tunnel terminates
|
CSCeh51949
|
No
|
Can no longer connect to ASA via WebVPN or ASDM->exhausted 8K blocks
|
CSCeh60845
|
No
|
Logginig queue incorrectly registers 8192 256-byte blocks
|
CSCeh84006
|
No
|
Wrong http version number should not be allowed
|
CSCeh90617
|
No
|
Recompiling ACLs can cause packet drops on low-end platforms
|
CSCeh93834
|
No
|
RSA SecurID replica list is lost after reboot
|
CSCei02273
|
No
|
1st log message is not sent by mail in transparent firewall
|
CSCei43588
|
No
|
traceback when trying to match a packet to acl with deny
|
CSCej04099
|
No
|
static xlate breaks management-access inside
|
CSCsb28708
|
No
|
Console traceback using show route command
|
CSCsb40188
|
No
|
SCEP fails if RA cert has 4096 bit key
|
CSCsb41742
|
No
|
P2P/IM/tunneling traffic is only dropped if strict-http action is drop
|
CSCsb51038
|
No
|
Traceback: _snp_sp_create_flow+1937 with outbound ACL and Policy Statics
|
CSCsb80170
|
No
|
Address-pools needed in group-policy - missing functionality from VPN3K
|
CSCsb81593
|
No
|
removing sunrpc-server cli doesnt stop sunrpc traffic from getting thru
|
CSCsb90046
|
No
|
GTP context creation might fail w/ Tunnel Limit xxx exceeded error
|
CSCsb99385
|
No
|
strict-http: with a space before http ver should generate a tcp reset
|
CSCsc00176
|
No
|
clear xlate take 4.5+ mins to clear 60K PAT xlat
|
CSCsc01017
|
No
|
ASA to VPN3K L2L fails rekey w/ main mode, 3des, sha, rsa, pfs-2, dh-2
|
CSCsc02485
|
No
|
Session Cmd: sendind \036x\r to exit session to ssm causes Traceback
|
CSCsc07421
|
No
|
Traceback in Dispatch Unit - decoding h323 ras message
|
CSCsc07614
|
No
|
Minimum unit poll time causes trouble for failover with 4GE card
|
CSCsc10617
|
No
|
GTP: memory leakage after <clear config all> at gtp_init
|
CSCsc11724
|
No
|
Logging: Wrong behaivor if syslog is sent to a nonfunctioning tcp server
|
CSCsc12094
|
No
|
AAA fallback authentication does not work with reactivation-mode timed
|
CSCsc14591
|
No
|
xlate and xlate perfmon print graph are all zeros
|
CSCsc15434
|
No
|
Assertion violation w/icmp traffic and icmp inspection
|
CSCsc16041
|
No
|
'clear local host' results in memory leak
|
CSCsc16503
|
No
|
Transparent firewall ASR UDP out traffic got errors and inbound failed
|
CSCsc16607
|
No
|
fixup pptp fails with static pat server configuration
|
CSCsc17051
|
No
|
VPNFO: VPN Failover fails to parse P2 SA when IPCOMP is used
|
CSCsc17409
|
No
|
dhcprelay: ASA blocks RELEASE packets
|
CSCsc17428
|
No
|
Tracebacks with ci/console with 'clear config all'
|
CSCsc18444
|
No
|
Tunnel-group for specific peer not created upgrading to 7.0 w/ certs
|
CSCsc18911
|
No
|
ASA does not remove OSPF route for global PAT entry after deleting
|
Resolved Caveats - Release 7.0(4)
Table 4 Resolved Caveats
ID Number
|
Software Release 7.0(4)
|
Corrected
|
Caveat Title
|
CSCeg67989
|
Yes
|
WebVPN: Logo file is not working correctly
|
CSCeh81062
|
Yes
|
wrong ip addr on outgoing packets when PAT and static port are used
|
CSCeh90309
|
Yes
|
Checkheaps process crashes while dumping corrupted memory blocks
|
CSCeh90617
|
Yes
|
Recompiling ACLs can cause packet drops on low-end platforms
|
CSCeh97228
|
Yes
|
cTCP: cTCP connection are dropped sporadically when connected F1 Bet
|
CSCei00497
|
Yes
|
PIX/ASA 7.0 doesnt encrypt packets if next hop is PIX interface.
|
CSCei20466
|
Yes
|
Increase in CPU utilization when OSPF is enabled
|
CSCei20682
|
Yes
|
FWSM uptime stops at 49 days 17 hours
|
CSCei23290
|
Yes
|
DHCP Relay fails when static specified
|
CSCei24062
|
Yes
|
Some hosts in the network connects to inside intf cannot be reached
|
CSCei33166
|
Yes
|
Crash while pinging through a L2L tunnel w/ 10,000 byte pings
|
CSCei33782
|
Yes
|
Simultaneous TFTP connections are not closed properly
|
CSCei38012
|
Yes
|
DHCP Server should check for correct network upon REQUEST for rebind
|
CSCei38640
|
Yes
|
AAA: radius /w expiry does not work when using funk radius server
|
CSCei38644
|
Yes
|
VPN3000 does not properly handle State Attribute
|
CSCei38647
|
Yes
|
IKE SA stuck in MM_DONE state
|
CSCei38651
|
Yes
|
NT auth for VPN clients do not work with domainuser or user@domain
|
CSCei38657
|
Yes
|
P1 rekey may fail when P1/P2 rekeying and retransmit required
|
CSCei38667
|
Yes
|
Can't differentiate between root CA certs that have been re-keyed
|
CSCei38669
|
Yes
|
IPSec rekey causes tunnel to drop
|
CSCei41326
|
Yes
|
AAA: fallback to LOCAL authentication does not work for SSH
|
CSCei43065
|
Yes
|
Traceback - 0x004a21b0 ojb-f1/c_crypto_map:_crypto_map_remove_np+80
|
CSCei43133
|
Yes
|
traceback eip 0x006026a4 obj-f1/snp_ha_db in ci/console af cleconfal
|
CSCei44143
|
Yes
|
Crash in malloc.c if removing ACE from ACL
|
CSCei50190
|
Yes
|
ASA not accepting 2 ISAKMP policies with different AES types
|
CSCei50691
|
Yes
|
traceback with ASR enabled for session with 2ndary conn in TFW mode
|
CSCei51783
|
Yes
|
Group enumeration possible on Benetton platform
|
CSCei51867
|
Yes
|
Usability - crypto config should be grouped together in CLI output
|
CSCei52413
|
Yes
|
ASA fails to import cert if CA issuer has 4096 bits cert
|
CSCei52906
|
Yes
|
Routes assoc. w/ net ext tunnels fail to get removed after tun drop
|
CSCei54438
|
Yes
|
Inspects that use TCP proxy must enable dual TCP normalizer mode
|
CSCei56278
|
Yes
|
All access-lists removed when removing one
|
CSCei57279
|
Yes
|
Cascading ACL: Deny rules not working after tunnel established
|
CSCei62347
|
Yes
|
acl interval default value not show when inactive parameter used
|
CSCei64608
|
Yes
|
GTP: box reloads when Create Response has 3rd party GSN addr
|
CSCei67952
|
Yes
|
GTP: PDP Context expires even when data is present in the tunnel
|
CSCei68679
|
Yes
|
Traceback on telnet TACACS+ authentication through the firewall.
|
CSCei68679
|
Yes
|
Traceback on telnet TACACS+ authentication through the firewall.
|
CSCei70172
|
Yes
|
TCP dynamic proxy doesnt fast retransmit lost packet
|
CSCei70785
|
Yes
|
TCP proxy must send data from retransmit queue when ACK is received
|
CSCei71868
|
Yes
|
Deny message for inbound traffic with no access-list changed
|
CSCei75013
|
Yes
|
confg doesnt get copied to admin ctx when changing mode SRM->MRM
|
CSCei78667
|
Yes
|
URL filtering: misc issues related to request exhaustion and cleanup
|
CSCei81803
|
Yes
|
Assert in validate_chunk() during startup
|
CSCei83304
|
Yes
|
clear conf sec doesnt clear igmp and ospf param in ifx submode
|
CSCei84925
|
Yes
|
traceback obj-f1/snp_tfw:_snpi_tfw_update_l2_entry+75 af apply conf
|
CSCei87390
|
Yes
|
Removing failover group causes traceback with 4GE installed
|
CSCei87785
|
Yes
|
MGCP: Call cannot be placed with IP phone using BTS CA & version 1.0
|
CSCei92828
|
Yes
|
Authentication failing for virtual telnet/http in transperent mode
|
CSCei93112
|
Yes
|
Existing connections not replicated to standby after failover
|
CSCei93790
|
Yes
|
Clear configure all in single transparent mode causes traceback
|
CSCej08898
|
Yes
|
tcpintercept caused trcback.embconn=0,maxconn!=0,eip:0x00c32dbc
|
CSCej12123
|
Yes
|
OSPF external routes preferred over internal with multiple processes
|
CSCej24446
|
Yes
|
error in processing IKE
|
CSCsb32565
|
Yes
|
Device reboots unexpectedly with traceback
|
CSCsb36441
|
Yes
|
Traceback eip _snp_fp_inspect_ip_options with IP Frag and 10 KB ping
|
CSCsb37531
|
Yes
|
Traceback after failover if TCP Intercept is triggered.
|
CSCsb45373
|
Yes
|
Traceback tcp_slow after vpn system test script strtd snd cfg setupUUT
|
CSCsb45584
|
Yes
|
Traceback eip _snp_ids_cleanup_cb with ips promiscuous and 100 byte ping
|
CSCsb46603
|
Yes
|
GTP: Responses that reject Create Requests are dropped
|
CSCsb46862
|
Yes
|
Assertion in ctm_sw_rng_x931.c:update_key
|
CSCsb47027
|
Yes
|
ASA crashed eip 0x00b8773c (image 7.0.2.1)
|
CSCsb47825
|
Yes
|
F1 fails to establish TCP remote access sessions with 3002 HW client
|
CSCsb49125
|
Yes
|
F1 crashes at <show debug> command
|
CSCsb49744
|
Yes
|
WebVPN: New crash behavior w buffer capture
|
CSCsb50946
|
Yes
|
High cpu due to shun command
|
CSCsb52950
|
Yes
|
With banner exec command and # as delimiter replication not correct
|
CSCsb53407
|
Yes
|
MFIB: tracebacks when bouncing multicast-routing
|
CSCsb54403
|
Yes
|
mcast: asa crashes after inside router pings 226.1.1.1
|
CSCsb54545
|
Yes
|
Traceback eip _keyword_option_flex_action with show ip local pool
|
CSCsb55282
|
Yes
|
sh inventory does not show 4GE module
|
CSCsb55550
|
Yes
|
traceback in pki_ctm:_pki_ctm_verify_signature+164 - 8192 bit certs conn
|
CSCsb56247
|
Yes
|
traceback in crypto_pki:_crypto_pki_poll_crl+52 - with crl opt PKI
|
CSCsb56367
|
Yes
|
webvpn: assertion in thread emweb/https when max webvpn sessions reached
|
CSCsb58364
|
Yes
|
VPNFO: tunnels get dropped when fover occurs
|
CSCsb58364
|
Yes
|
VPNFO: tunnels get dropped when fover occurs
|
CSCsb60861
|
Yes
|
WebVPN session attempt with proto=webvpn off, causes emweb crash
|
CSCsb61027
|
Yes
|
mcast: secondary crashes shortly after sync'd with primary
|
CSCsb61544
|
Yes
|
WebVPN: Traceback within obj-f1/http_ewa:_ewaNetHTTPSend+162
|
CSCsb61644
|
Yes
|
ASA crashes when acessing ASDM over IPSec/TCP-10000 tunnel
|
CSCsb61832
|
Yes
|
HTTP-Proxy functionality (Port Forwarding) not working on Windows ME
|
CSCsb62617
|
Yes
|
VPN: assertion 0 failed: file malloc.c, line 4570 RA dial/hang test
|
CSCsb62908
|
Yes
|
Closing the Port Forwarding Applet removes existing Proxy configuration
|
CSCsb63920
|
Yes
|
CLI: no ssl trust-point cmmd causes traceback, ssl_chain:_ssl_trustpoint
|
CSCsb64159
|
Yes
|
VPNLB: need ability to assign a trustpoint to the vcpip address
|
CSCsb64985
|
Yes
|
4ge module interface stops passing traffic after using QoS and L2L tunn
|
CSCsb67119
|
Yes
|
Inspect ESMTP incorrectly rewrites smtp reply containing 220 in text
|
CSCsb67166
|
Yes
|
Time based ACLs not working properly if object groups are used
|
CSCsb70268
|
Yes
|
'hw-module module 1 reload reloads 4GE module
|
CSCsb71198
|
Yes
|
incorrectly formatted DL ACL causes traceback in IKE daemon
|
CSCsb72604
|
Yes
|
crash in snmp thread after nmap UDP scan of port 161
|
CSCsb72665
|
Yes
|
IX 7 may drop valid TCP segments that carry data in final segment
|
CSCsb72803
|
Yes
|
rash triggered when system is out of memory
|
CSCsb74050
|
Yes
|
F1 crashed when sweep-ping (G-PDU) thru GTP tunnel v0
|
CSCsb74836
|
Yes
|
MFW-R: ASA crash on SSM reboot from IDM
|
CSCsb75857
|
Yes
|
F1 hit memory corrution crash @ clear conf gtp then clear conf all
|
CSCsb76268
|
Yes
|
Immediately after upgrade to 7.0(1) - interfaces stuck in waitingstate
|
CSCsb77332
|
Yes
|
traceback in fover_parse on standby unit if config contains webtype acl
|
CSCsb77397
|
Yes
|
Traceback: eip 0x00c3426c strcpy:_strcpy+12, using deb menu ike commands
|
CSCsb78230
|
Yes
|
hw-module module 1 shut and reset do not bring up the 4ge module
|
CSCsb79742
|
Yes
|
incorrectly formatted downloadable acl causes traceback in emweb/https
|
CSCsb80196
|
Yes
|
DHCP ID String is limited to 50 characters, should be 128
|
CSCsb81575
|
Yes
|
key gen causes an assert if ASA has DES only license
|
CSCsb82663
|
Yes
|
Out of order TCP packets degrade HTTP inspection performance
|
CSCsb83962
|
Yes
|
F1 OSPF regression scripts hang with removal of router config
|
CSCsb85767
|
Yes
|
URL Filtering with long URLs could cause memory corruption
|
CSCsb85780
|
Yes
|
Malformed HTTP GET request causes URL filtering module to cause a crash.
|
CSCsb88557
|
Yes
|
Traceback at snap:_snap_mini_dump+26 with acl Logging: thread-arp_timer
|
CSCsb89147
|
Yes
|
certificate-to-username mapping broken for some DN attributes
|
CSCsb91835
|
Yes
|
ASA reload in smtp/esmtp inspection {insp_process_smtp_data}
|
CSCsb91837
|
Yes
|
vpn-filter incorrectly blocking traffic with echo, echo-response keyword
|
CSCsb93659
|
Yes
|
Local IP doesn't get translated with NAT Exemption
|
CSCsb94651
|
Yes
|
Overlapping static statements should be allowed
|
CSCsb94689
|
Yes
|
4GE card firmware accessing incorrect PHY address
|
CSCsb95027
|
Yes
|
Stadby Betabox rebooted while upgrading to 7.0.3.19
|
CSCsb95259
|
Yes
|
No hits shown on access-list associated to a group-policy vpn-filter
|
CSCsb97680
|
Yes
|
traceback in radpact:_RADPBldHWClientReauth+260 during 3002 New Pin Mode
|
CSCsb99192
|
Yes
|
Show access-list | inc xxx causes traffic through device to be delayed
|
CSCsb99360
|
Yes
|
Logging queue 0 is wrongly shown as being unlimited queue
|
CSCsc00709
|
Yes
|
ASA enable authentication issue
|
CSCsc02230
|
Yes
|
nat entry with outside keyword : ERROR: unable to download policy
|
CSCsc02485
|
Yes
|
Session Cmd: sendind 036xr to exit session to ssm causes Traceback
|
CSCsc02574
|
Yes
|
pki: ID cert signature validation failure allows successful connection
|
CSCsc06282
|
Yes
|
fover: ip local pool fails to replicate after issuing from grp submode
|
CSCsc06477
|
Yes
|
unable to manage running config with err msg: configuration in progress
|
CSCsc06702
|
Yes
|
VPN: Interface counters are incorrectly incremented on decrypted packets
|
CSCsc08843
|
Yes
|
DHCP-Relay drops packets when source address is non-zero
|
CSCsc09527
|
Yes
|
VPNFO: cannot establish a vpn tunnel "session limit reached" sa cnt -1
|
CSCsc09932
|
Yes
|
Assertion in file "vf_api.c", line 264, traceback in strdup:_int3+4
|
CSCsc14837
|
Yes
|
ARP fails on the 4GE interfaces in routed firewall mode
|
Related Documentation
For additional information on the Cisco ASA 5500 series security appliance, refer to the following documentation found on Cisco.com:
•Cisco ASA 5500 Hardware Installation Guide
•Cisco ASA 5500 Quick Start Guide
•Cisco Security Appliance Command Line Configuration Guide
•Cisco Security Appliance Command Reference
•Migrating to ASA for VPN 3000 Series Concentrator Administrators
Software Configuration Tips on the Cisco TAC Home Page
The Cisco Technical Assistance Center has many helpful pages. If you have a CDC account you can visit the following websites for assistance:
TAC Troubleshooting, Sample Configurations, Hardware Info, Software Installations and more:
http://www.cisco.com/en/US/products/hw/vpndevc/ps2030/
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What's New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What's New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS version 2.0.
Feedback
